Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-8: Channel bandwidth ≥4 GHz models
Reference
Vertical amplitude Horizontal
scale (6 div) scale
10 mV 60 mV 1 ns
20 mV 120 mV 1 ns
50 mV 300 mV 1 ns
100 mV 600 mV 1 ns
200 mV 1.5 V 1 ns
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Test frequency
DSA/ DSA/ DSA/
DPO72004C, DPO71604C, DPO71254C,
MSO72004C MSO71604C MSO71254C
18 GHz 16 GHz 12.5 GHz
20 GHz 16 GHz 12.5 GHz
20 GHz 16 GHz 12.5 GHz
20 GHz 16 GHz 12.5 GHz
20 GHz 16 GHz 12.5 GHz

Table 3-9: Channel bandwidth 3.5 GHz model

Vertical Reference
scale amplitude
5 mV 30 mV
10 mV 40 mV
20 mV 80 mV
50 mV 200 mV
100 mV 400 mV
200 mV 800 mV
500 mV 2 V 1
1 V 4 V 1
1
If your generator cannot output the required amplitude, determine its maximum output at the Test frequency,
and use this for the reference amplitude. The -3 dB limit can be calculated as: 0.707 × reference amplitude.
b. Match the trigger source to the channel selected: Press the Trigger
Source button until the source that corresponds to the channel you are
to confirm is on.
≥ 3.5 GHz models with bandwidth >9 GHz: Set the trigger Source to Line.
c. DPO7354: Set the input impedance to 50 Ω.
d. Set the vertical scale:
For the channel you are testing, set the vertical Scale to the next setting
listed in the tables, starting with the 100 mV setting. See the preceding
Channel Bandwidth table that applies to your instrument.
DSA/ DSA/ DSA/
DPO70804B, DPO70604B, DPO70404B,
MSO70804 MSO70604 MSO70404
8 GHz 6 GHz 4 GHz
8 GHz 6 GHz 4 GHz
8 GHz 6 GHz 4 GHz
8 GHz 6 GHz 4 GHz
8 GHz 6 GHz 4 GHz
Test
frequency
Horizontal
scale DPO7354
1 ns 2.0 GHz
1 ns 3.5 GHz
1 ns 3.5 GHz
1 ns 3.5 GHz
1 ns
3.5 GHz
1 ns 3.5 GHz
1 ns 3.5 GHz
1 ns 3.5 GHz
-3 dB
limits
≥42.4 mV
≥84.8 mV
≥212 mV
≥424 mV
≥1.061 V
-3 dB limits
≥21.2 mV
≥28.3 mV
≥56.6 mV
≥141.4 mV
≥283 mV
≥566 mV
≥1.41 V 1
≥2.83 V 1
3–67
