Tektronix MSO70000 Series Technical Reference page 116

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
9. Generator, Sine-Wave
10. Meter, Level and Power
Sensor
11. Splitter, Power
12. Cable
13. Adapter
14. Adapter (four required)
15. Adapter
16. Adapter (three required)
17. Adapter (three required)
18. Adapter
19. Adapter (four required)
20. Pulse Generator
3–20
Minimum requirements
Instrument bandwidth ≤3 GHz:
5 kHz to at least the instrument
bandwidth. Variable amplitude
from 60 mV to 2 V into 50 Ω.
p-p
Frequency error <2.0%
Instrument bandwidth >3 GHz:
50 MHz to at least the
instrument bandwidth.
Variable amplitude from
60 mV to 2.0 V into 50 Ω.
p-p
Frequency error <2.0%
Frequency range: 50 MHz
to the instrument bandwidth.
Amplitude range: 6 mV to
p-p
2 V
p-p
Instrument bandwidth ≤3 GHz:
Frequency range: DC to
18 GHz. Tracking: <2.0%
Instrument bandwidth >3 GHz:
Frequency range: DC to
40 GHz. Tracking: <2.0%
2.92 mm male-to-female
K male-to-male DC to 40 GHz
Male N-to-female BNC
Female N-to-male BNC
SMA female-to-female
SMA male-to-female BNC
BNC to Minigrabber
SMA male-to-BNC female
250 MHz, ≤ 150 ps rise time,
5 V out
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Example
Fluke 9500B 1
Anritsu MG3692B or
MG3694B Synthesized
CW Generator with options
2x (step attenuator), 3 (low
noise >2 GHz), 4 (10 MHz to
2 GHz low phase noise), 15
(high power), and 16 (high
stability)
Rohde & Schwarz NRVS and
NRV-Z15 (40 GHz)
Agilent part number 11667A
Anritsu K241C (40 GHz)
Gore PhaseFlex cable
EL0CQ0CP0360 (40 GHz)
Anritsu K220B
Tektronix part number
103-0045-00
Tektronix part number
103-0058-00 (4 GHz)
Tektronix part number
015-1012-00 (18 GHz)
Tektronix part number
015-1018-00
Tektronix part number
013-0342-xx
TCA-BNC or TCA-292mm
and, if required, SMA
male-to-BNC female adapter
(Tektronix part number
015-0554-00 (4 GHz) or
015-1018-00)
Fluke 9500B 1 , 2
Purpose
Checking analog bandwidth,
trigger sensitivity,
sample-rate, external clock,
trigger sensitivity, time
qualified trigger, baud rate
limit, clock recovery, and
delay-time accuracy
Checking analog bandwidth
and Trigger Sensitivity
Checking trigger sensitivity
and analog bandwidth
Checking analog bandwidth
Checking analog bandwidth
Checking analog bandwidth
Checking analog bandwidth
Checking trigger sensitivity
Checking the delay between
channels, delta time
Checking probe
compensation output
Signal interconnection,
measurement accuracy,
delay time, time qualified
trigger, trigger sensitivity,
DC gain, offset, bandwidth,
input resistance, probe
compensation out, baud rate
limit, clock recovery
Used to test delta time
measurement accuracy
