Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test
Baud rate limits
Serial word recognizer
Signal path 0, Pattern matching 1
Trigger 1 UI before 0
Trigger on 0
Trigger 1 UI after 0
Signal path 1, Pattern matching 1
Trigger 1 UI before 1
Trigger on 1
Trigger 1 UI after 1
Clock recovery frequency range
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Minimum Incoming
Pass __________
Pass __________
Pass __________
Pass __________
Pass __________
Pass __________
__________
Pass
Outgoing Maximum
__________ N/A
__________ N/A
__________ N/A
__________ N/A
__________ N/A
__________ N/A
__________
N/A
