Performance Verification (MSO/DPO5000 Series)
DC Balance
Performance checks Vertical scale
Channel 2 DC Balance, 1 mV/div
50 Ω, 20 MHz BW
2 mV/div
10 mV/div
100 mV/div
1 V/div
Channel 2 DC Balance, 1 mV/div
1 MΩ, 20 MHz BW
2 mV/div
10 mV/div
100 mV/div
1 V/div
10 V/div
Channel 2 DC Balance, 1 mV/div
50 Ω, 175 MHz BW
Channel 2 DC Balance, 1 mV/div
1 MΩ, 175 MHz BW
Channel 2 DC Balance, 2 mV/div
50 Ω, 250 MHz BW
10 mV/div
100 mV/div
1 V/div
Channel 2 DC Balance, 2 mV/div
1 MΩ, 250 MHz BW
10 mV/div
100 mV/div
1 V/div
10 V/div
Channel 2 DC Balance, 1 mV/div
50 Ω, Full BW
2 mV/div
10 mV/div
100 mV/div
1 V/div
Channel 2 DC Balance, 1 mV/div
1 MΩ, Full BW
2 mV/div
10 mV/div
100 mV/div
1 V/div
10 V/div
4–4
Low limit
-0.2 mV
-0.2 mV
-1 mV
-10 mV
-100 mV
-0.2 mV
-0.4 mV
-2 mV
-20 mV
-200 mV
-2 V
-0.2 mV
-0.2 mV
-0.2 mV
-1 mV
-10 mV
-100 mV
-0.4 mV
-2 mV
-20 mV
-200 mV
-2 V
-0.2 mV
-0.2 mV
-1 mV
-10 mV
-100 mV
-0.2 mV
-0.4 mV
-2 mV
-20 mV
-200 mV
-2 V
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Test result High limit
0.2 mV
0.2 mV
1 mV
10 mV
100 mV
0.2 mV
0.4 mV
2 mV
20 mV
200 mV
2 V
0.2 mV
0.2 mV
0.2 mV
1 mV
10 mV
100 mV
0.4 mV
2 mV
20 mV
200 mV
2 V
0.2 mV
0.2 mV
1 mV
10 mV
100 mV
0.2 mV
0.4 mV
2 mV
20 mV
200 mV
2 V
