Tektronix MSO70000 Series Technical Reference page 26

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
Characteristic
MSO70804,
DSA/DPO70804B,
MSO70604,
DSA/DPO70604B,
MSO70404,
DSA/DPO70404B
Calculated rise time, 50 Ω, typical
≥ 4 GHz models
MSO/DSA/DPO72004C
at 20 GHz
MSO/DSA/DPO72004C
at 18 GHz
MSO/DSA/DPO71604C
MSO/DSA/DPO71254C
MSO70804,
DSA/DPO70804B
MSO70604,
DSA/DPO70604B
MSO70404,
DSA/DPO70404B
1–10
Description
Step settings
± 0.5 dB from DC to 50% of nominal bandwidth.
± 1 dB from 50% to 80% of nominal bandwidth.
Typical temperature variation
Frequency
DC — 11 GHz
12.5 GHz
16 GHz
18 GHz
20 GHz
DSP On
10% - 90% 20% - 80%
19.0 ps 14 ps
22 ps 15 ps
24.5 ps 17 ps
32.0 ps 22 ps
49 ps 34 ps
65 ps 45 ps
98 ps 68 ps
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
TC, (dB/°C)
0
– 0.02
– 0.04
– 0.09
– 0.09
DSP Off
10% - 90%
NA
NA
30 ps
33 ps
47 ps
62 ps
93 ps
10 °C to 40 °C
20% - 80%
NA
NA
20 ps
23 ps
32 ps
43 ps
65 ps
