Tektronix MSO70000 Series Technical Reference page 141

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-4: DC voltage measurement accuracy (cont.)
Position setting
Scale setting (Divs)
< 4 GHz models
1 mV -5
+5
2 mV -5
+5
5 mV -5
+5
-5
10 mV
+5
20 mV -5
+5
50 mV -5
+5
90 mV -5
+5
100 mV 0
0
200 mV -2
+2
500 mV -2
+2
1 V 0
0
1 Set as precisely as the instrument's offset resolution permits.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Offset setting 1 Generator setting
+0.5 V +507 mV
-0.5 V -507 mV
+0.5 V +516 mV
-0.5 V -516 mV
+0.5 V +540 mV
-0.5 V -540 mV
+0.5 V +580 mV
-0.5 V -580 mV
+0.5 V +660 mV
-0.5 V -660 mV
+0.5 V +900 mV
-0.5 V -900 mV
+0.5 V +1.22 V
-0.5 V -1.22 V
+4.5 V +4.8 V
-4.5 V -4.8 V
+4.6 V +4.8 V
-4.6 V -4.8 V
+5.0 V +4.5 V
-5.0 V -4.5 V
+2.0 V +5.0 V
-2.0 V -5.0 V
Accuracy limits
+504.25 mV to +509.76 mV
-509.76 mV to -504.25 mV
+512.98 mV to +519.03 mV
-519.03 mV to -512.98 mV
+536.26 mV to +543.74 mV
-543.74 mV to -536.26 mV
+574.20 mV to +585.80 mV
-585.80 mV to -574.20 mV
+651.65 mV to +668.35 mV
-668.35 mV to -651.65 mV
+884.00 mV to +916.00 mV
-916.00 mV to -884.00 mV
+1.194 V to +1.246 V
-1.246 V to -1.194 V
+4.746 V to +4.854 V
-4.854 V to -4.746 V
+4.725 V to +4.875 V
-4.875 V to -4.725 V
+4.345 V to +4.655 V
-4.655 V to -4.345 V
+4.745 V to +5.255 V
-5.255 V to -4.745 V
3–45
