Tektronix MSO70000 Series Technical Reference page 132

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test
Ch4
1 V
500 mV
200 mV
100 mV
50 mV
20 mV
10 mV
5 mV
Input resistance, ≥ 4 GHz models
Ch1 10 mV/div
Ch1 100 mV/div
Ch2 10 mV/div
Ch2 100 mV/div
Ch3 10 mV/div
Ch3 100 mV/div
Ch4 10 mV/div
Ch4 100 mV/div
3–36
Minimum
2.83 V
1.41 V
566 mV
283 mV
141.4 mV
56.6 mV
28.3 mV
21.2 mV
49.0 Ω
47.8 Ω
49.0 Ω
47.8 Ω
49.0 Ω
47.8 Ω
49.0 Ω
47.8 Ω
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Incoming Outgoing
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
Maximum
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
51.0 Ω
52.2 Ω
51.0 Ω
52.2 Ω
51.0 Ω
52.2 Ω
51.0 Ω
52.2 Ω
