Tektronix MSO70000 Series Technical Reference page 126

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test
Ch1 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
Ch1 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
Ch2 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
Ch2 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
Ch2 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
Ch2 100 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +2.0 V offset
+5 Div position setting, -2.0 V offset
Ch2 200 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +1.25 V offset
+5 Div position setting, -1.25 V offset
Ch2 500 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, 0 V offset
+5 Div position setting, 0 V offset
Ch3 10 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.45 V offset
+5 Div position setting, -0.45 V offset
Ch3 20 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.4 V offset
+5 Div position setting, -0.4 V offset
Ch3 50 mV Vert scale setting,
0 Div position setting, 0 V offset
-5 Div position setting, +0.25 V offset
+5 Div position setting, -0.25 V offset
3–30
Minimum
+ 1.49 V
+ 1.849 V
+ 1.49 V
+ 3.724 V
+ 3.724 V
+ 3.724 V
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
+ 744.80 mV
+ 744.80 mV
+ 744.80 mV
+ 1.49 V
+ 1.49 V
+ 1.49 V
+ 3.724 V
+ 3.724 V
+ 3.724 V
+ 74.48 mV
+ 74.48 mV
+ 74.48 mV
+ 148.96 mV
+ 148.96 mV
+ 148.96 mV
+ 372.40 mV
+ 372.40 mV
+ 372.40 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Incoming Outgoing
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
Maximum
+ 1.55 V
+ 1.55 V
+ 1.55 V
+ 3.876 V
+ 3.876 V
+ 3.876 V
+ 77.52 mV
+ 77.52 mV
+ 77.52 mV
+ 155.04 mV
+ 155.04 mV
+ 155.04 mV
+ 387.60 mV
+ 387.60 mV
+ 387.60 mV
+ 775.20 mV
+ 775.20 mV
+ 775.20 mV
+ 1.55 V
+ 1.55 V
+ 1.55 V
+ 3.876 V
+ 3.876 V
+ 3.876 V
+ 77.52 mV
+ 77.52 mV
+ 77.52 mV
+ 155.04 mV
+ 155.04 mV
+ 155.04 mV
+ 387.60 mV
+ 387.60 mV
+ 387.60 mV
