Tektronix MSO70000 Series Technical Reference page 27

Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
Characteristic
Calculated rise time, 50 Ω, typical
< 4 GHz models
DPO7354
1 mV/div - 1.99 mV/div
2 mV/div - 4.99 mV/div
5 mV/div - 9.9 mV/div
10 mV/div - 1 V/div,
BWE off
10 mV/div - 1 V/div,
BWE on
DPO7254
1 mV/div - 1.99 mV/div
2 mV/div - 4.99 mV/div
5 mV/div - 9.9 mV/div
10 mV/div - 1 V/div
DPO7104
1 mV/div - 1.99 mV/div
2 mV/div - 4.99 mV/div
5 mV/div - 9.9 mV/div
10 mV/div - 1 V/div
DPO7054
1 mV/div - 1.99 mV/div
2 mV/div - 4.99 mV/div
5 mV/div - 9.9 mV/div
10 mV/div - 1 V/div
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Description
10% - 90%
1.2 ns
650 ps
180 ps
145 ps
115 ps (signals limited to 4 vertical divisions)
1.2 ns
650 ps
180 ps
160 ps
1.2 ns
580 ps
300 ps
300 ps
1.2 ns
680 ps
460 ps
460 ps
1–11
