Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test
Ch1 90 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch1 90 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch1 100 mV Vert scale setting,
0 Div position setting, +4.5 V offset
Ch1 100 mV Vert scale setting,
0 Div position setting, -4.5 V offset
Ch1 200 mV Vert scale setting,
-2 Div position setting, +4.6 V offset
Ch1 200 mV Vert scale setting,
+2 Div position setting, -4.6 V offset
Ch1 500 mV Vert scale setting,
-2 Div position setting, +5.0 V offset
Ch1 500 mV Vert scale setting,
+2 Div position setting, -5.0 V offset
Ch1 1.0 V Vert scale setting,
0 Div position setting, +2.0 V offset
Ch1 1.0 V Vert scale setting,
0 Div position setting, -2.0 V offset
Ch2 1 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch2 1 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch2 2 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch2 2 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch2 5 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch2 5 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch2 10 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch2 10 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch2 20 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch2 20 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch2 50 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
3–26
Minimum
+ 1.194 V
- 1.246 V
+ 4.746 V
- 4.854 V
+ 4.725 V
- 4.875 V
+ 4.345 V
- 4.655 V
+ 4.745 V
- 5.255 V
+ 504.25 mV
- 509.76 mV
+ 512.98 mV
- 519.03 mV
+ 536.26 mV
- 543.74 mV
+ 574.20 mV
- 585.80 mV
+ 651.65 mV
- 668.35 mV
+ 884.00 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Incoming Outgoing
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
Maximum
+ 1.246 V
- 1.194 V
+ 4.854 V
- 4.746 V
+ 4.875 V
- 4.725 V
+ 4.655 V
- 4.345 V
+ 5.255 V
- 4.745 V
+ 509.76 mV
- 504.25 mV
+ 519.03 mV
- 512.98 mV
+ 543.74 mV
- 536.26 mV
+ 585.80 mV
- 574.20 mV
+ 668.35 mV
- 651.65 mV
+ 916.00 mV
