Tektronix MSO70000 Series Technical Reference page 51

Table 1-2: Horizontal and acquisition system specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000
Series models (cont.)
Characteristic
Maximum record length, sample
mode, < 4 GHz models
Standard, DPO7354 and
DPO7254
DPO7104
DPO7054
Option 2RL installed,
DPO7354 and DPO7254
DPO7104
DPO7054
Option 5RL installed,
DPO7354 and DPO7254
DPO7104
DPO7054
Option 10RL installed,
DPO7354 and DPO7254
Maximum record length, HiRes
mode
Seconds/division range
≥ 4 GHz models
< 4 GHz models
Acquisition update rate, typical
≥ 4 GHz models
< 4 GHz models
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Description
The maximum record length depends on the number of active channels and the record length
options installed. Maximum record length is less in serial trigger mode, hi-res mode or when
using the FIR filter.
10 GS/s
20 GS/s or less
40 GS/s or less
5 GS/s
10 GS/s or less
20 GS/s or less
2.5 GS/s
5 GS/s or less
10 GS/s or less
10 GS/s
20 GS/s or less
40 GS/s or less
5 GS/s
10 GS/s or less
20 GS/s or less
2.5 GS/s
5 GS/s or less
10 GS/s or less
10 GS/s
20 GS/s or less
40 GS/s or less
5 GS/s
10 GS/s or less
20 GS/s or less
2.5 GS/s
5 GS/s or less
10 GS/s or less
10 GS/s
20 GS/s or less
40 GS/s or less
Half the record length of sample mode
Fastest sweep speed is 20 ps per division
Fastest sweep speed is 25 ps per division
Fast Acquisition on: 300,000 waveforms per second maximum
Fast Acquisition on: 250,000 waveforms per second maximum
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
125,000,000 points (3 or 4 channels)
250,000,000 points (2 channels only)
500,000,000 points (1 channel only)
1–35
