Tektronix MSO70000 Series Technical Reference page 40

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
MSO72004C,
MSO71604C,
MSO71254C,
DSA72004C,
DSA71604C,
DSA71254C,
DPO72004C,
DPO71604C,
DPO71254C
where applicable
Gain setting
10 mV
15 mV
20 mV
30 mV
40 mV
50 mV
60 mV
70 mV
80 mV
90 mV
100 mV
200 mV
250 mV
300 mV
400 mV
450 mV
500 mV
1–24
5 GHz 4 GHz 3 GHz
0.37 mV 0.34 mV 0.31 mV
0.51 mV 0.48 mV 0.44 mV
0.57 mV 0.53 mV 0.48 mV
0.84 mV 0.77 mV 0.69 mV
1.06 mV 0.98 mV 0.88 mV
1.22 mV 1.10 mV 1.03 mV
1.49 mV 1.35 mV 1.24 mV
1.76 mV 1.59 mV 1.45 mV
2.08 mV 1.96 mV 1.76 mV
2.29 mV 2.08 mV 1.88 mV
2.77 mV 2.65 mV 2.38 mV
5.28 mV 4.90 mV 4.43 mV
6.34 mV 5.83 mV 5.33 mV
7.40 mV 6.77 mV 6.22 mV
10.37 mV 9.51 mV 8.83 mV
11.53 mV 10.54 mV 9.81 mV
12.68 mV 11.57 mV 10.80 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
2 GHz 1 GHz 500 MHz
0.26 mV 0.20 mV 0.17 mV
0.39 mV 0.34 mV 0.27 mV
0.44 mV 0.37 mV 0.31 mV
0.61 mV 0.52 mV 0.44 mV
0.78 mV 0.66 mV 0.57 mV
0.91 mV 0.76 mV 0.68 mV
1.09 mV 0.91 mV 0.82 mV
1.27 mV 1.06 mV 0.95 mV
1.51 mV 1.22 mV 1.10 mV
1.63 mV 1.35 mV 1.22 mV
2.02 mV 1.57 mV 1.31 mV
4.12 mV 3.42 mV 2.88 mV
4.87 mV 4.07 mV 3.49 mV
5.63 mV 4.72 mV 4.10 mV
7.86 mV 6.63 mV 5.86 mV
8.68 mV 7.34 mV 6.53 mV
9.51 mV 8.06 mV 7.20 mV
