Tektronix MSO70000 Series Technical Reference page 136

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test
Trigger system accuracy
Time accuracy for time qualified triggers, < 4 GHz models,
time range < 1 ms
Lower Limit
Upper Limit
time range ≥ 1 μs
Lower Limit
Upper Limit
Time accuracy for time qualified triggers, ≥ 4 GHz models
time range < 1 ms
Lower Limit
Upper Limit
time range ≥ 1 μs
Lower Limit
Upper Limit
Ch1 trigger sensitivity, 50 MHz
Ch1 delayed trigger sensitivity ≥ 4 GHz models:
50 MHz
AUX trigger input sensitivity, 50 MHz
Ch1 trigger sensitivity
< 4 GHz models:
≥ 4 GHz models: 4 GHz
≥ 4 GHz models: 6 GHz
≥ 4 GHz models: 8 GHz
≥ 4 GHz models: 11 GHz
Ch1 B trigger sensitivity
≥ 4 GHz models: 4 GHz
≥ 4 GHz models: 6 GHz
≥ 4 GHz models: 9 GHz
Ch1 AUX trigger input
< 4 GHz models: 250 MHz
≥ 4 GHz models: 1 GHz
Aux trigger out
Vout Hi
Vout Lo
Probe compensation output signal Voltage (difference)
< 4 GHz models
≥ 4 GHz models
Serial trigger (≥ 4 GHz models with Option PTH or < 4 GHz models with Option PTM only)
3–40
Minimum
3.5 ns
3.5 ns
1.9 μs
1.9 μs
4.77 ns
4.77 ns
1.9 μs
1.9 μs
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
1.0 V
985 mV
343.2 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Incoming Outgoing
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
Maximum
6.5 ns
6.5 ns
2.1 μs
2.1 μs
5.23 ns
5.23 ns
2.1 μs
2.1 μs
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
0.25 V
1015 mV
536.8 mV
