Tektronix MSO70000 Series Technical Reference page 129

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performance test
Ch3 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
5 Div position setting, -1.25 V offset
Ch3 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
5 Div position setting, 0 V offset
Ch4 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
5 Div position setting, -0.45 V offset
Ch4 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
5 Div position setting, -0.4 V offset
Ch4 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
5 Div position setting, -0.25 V offset
Ch4 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
5 Div position setting, -2.0 V offset
Ch4 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
5 Div position setting, -1.25 V offset
Ch4 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
5 Div position setting, 0 V offset
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Minimum Incoming
+ 1.965 V __________
- 2.035 V __________
+ 2.434 V __________
- 2.566 V __________
+ 495.75 mV __________
- 504.25 mV __________
+ 494.75 mV __________
- 505.25 mV __________
+ 491.75 mV __________
- 508.25 mV __________
+ 2.474 V __________
- 2.526 V __________
+ 1.965 V __________
- 2.035 V __________
+ 2.434 V __________
- 2.566 V __________
Outgoing Maximum
__________ + 2.035 V
__________ - 1.965 V
__________ + 2.566 V
__________ - 2.434 V
__________ + 504.25 mV
__________ - 495.75 mV
__________ + 505.25 mV
__________ - 494.75 mV
__________ + 508.25 mV
__________ - 491.75 mV
__________ + 2.526 V
__________ - 2.474 V
__________ + 2.035 V
__________ - 1.965 V
__________ + 2.566 V
__________ - 2.434 V
3–33
