Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
Characteristic
Sensitivity range
≥ 4 GHz models, 50 Ω
< 4 GHz models, 50 Ω
< 4 GHz models, 1 MΩ
DC gain accuracy, sample or
average acquisition mode,
≥ 4 GHz models
DC gain accuracy, sample or
average acquisition mode,
< 4 GHz models
DC voltage measurement
accuracy, ≥ 4 GHz models
Average acquisition mode
( ≥16 averages)
Delta voltage measurement
between any two averages
of ≥16 waveforms acquired
under the same setup and
ambient conditions
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Description
100 mV/Full Scale to 5 V/Full Scale. Below 100 mV/Full Scale, Full Scale (FS) is software zoom.
1 mV/div to 1 V/division, in a 1-2-5 sequence
Fine adjustment available with ≥1% resolution
1 mV/div to 10 V/division, in a 1-2-5 sequence
Fine adjustment available with ≥1% resolution
± 2%
± 1.0% with 0 V net offset
Add 0.5% for ranges <2 mV/div
Add 1.5% x | net offset/Max offset | for ranges <5 mV/div
Add 0.5% x | net offset/Max offset | for ranges ≥ 5 mV/div
Add 0.5% for ranges ≥ 1 V/div in 1 MΩ coupling and with net offset >10 V
Gain setting
100 mV/FS to 995 mV/FS
1 V/FS to 5 V/FS
100 mV/FS to 5 V/FS
DC measurement accuracy
±[2% | reading - net offset | + 0.35% | net offset | +1.5 mV
+ 0.014 FS]
±[2% | reading - net offset | + 0.35% | net offset | +7.5 mV
+ 0.014 FS]
±[2% | reading | + 0.008 FS]
1–3
