Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)

Table 3-4: DC voltage measurement accuracy

Position setting
Scale setting (Divs)
≥ 4 GHz models
10 mV -5
+5
-5
20 mV
+5
50 mV -5
+5
100 mV -5
+5
-5
200 mV
+5
500 mV -5
+5
3–44
b. Turn on the measurement Mean for the channel:
From the button bar, touch Measure and select the Ampl tab, More,
and then touch Mean to measure the mean of the current channel.
Press the X (Close) button.
NOTE.
When setting the Fluke generator to output >5 V, use the following
procedure:
Press the Aux button
Press the fourth soft key down (Selects the pulse with an exclamation point)
Set the amplitude to 5.3 or 5.5 V
Press the ->| key to select the pulse energy
Set the energy to 50J, and press the Output On key
Press the Trig Pulse soft key to trigger the pulse (this will generate a pulse
with 25 seconds duration).
Use the normal DC output for the 1 V, 3 V, and 5 V generator settings.
NOTE. If any of the voltages supplied by your generator are not calibrated,
verify those generator voltages using a digital multimeter, item 27.
c. Set the vertical scale: Set the vertical Scale to one of the settings listed in
the following table that is not yet checked, starting with the first setting
listed.
Offset setting 1
+0.45 V
-0.45 V
+0.4 V
-0.4 V
+0.25 V
-0.25 V
+2.0 V
-2.0 V
+1.25 V
-1.25 V
0 V
0 V
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Generator setting Accuracy limits
+530 mV +524.75 mV to +535.25 mV
-530 mV -535.25 mV to -524.75 mV
+560 mV +552.75 mV to +567.25 mV
-560 mV -567.25 mV to -552.75 mV
+650 mV +636.75 mV to +663.25 mV
-650 mV -663.25 mV to -636.75 mV
+2.8 V +2.764 V to 2.836 V
-2.8 V -2.836 V to -2.764 V
+2.75 V +2.697 V to 2.803 V
-2.75 V -2.803 V to -2.697 V
+3.5 V +3.394 V to 3.606 V
-3.5 V -3.606 V to -3.394 V
