Tektronix MSO70000 Series Technical Reference page 55

Table 1-2: Horizontal and acquisition system specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000
Series models (cont.)
Characteristic
MSO/DSA/DPO71254C at
50 GS/s, BWE off
MSO70804 and
DSA/DPO70804B at
25 GS/s, BWE off
MSO70604 and
DSA/DPO70604B at
25 GS/s, BWE off
MSO70404 and
DSA/DPO70404B at
25 GS/s, BWE off
MSO/DSA/DPO72004C at
50 GS/s, 20 GHz, BWE on
MSO/DSA/DPO72004C at
50 GS/s, 18 GHz, BWE on
MSO/DSA/DPO72004C,
MSO/DSA/DPO71654C at
50 GS/s, 16 GHz, BWE on
MSO/DSA/DPO72004C,
MSO/DSA/DPO71654C,
MSO/DSA/DPO71254C at
50 GS/s, 12.5 GHz, BWE on
MSO70804,
DSA/DPO70804B at
25 GS/s, 8 GHz, BWE
on
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Description
1.304 ps rms, 13.04 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.201 ps rms, 12.01 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.205 ps rms, 12.05 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.462 ps rms, 14.62 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.295 ps rms, 12.95 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.336 ps rms, 13.36 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.625 ps rms, 16.25 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.427 ps rms, 14.27 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.463 ps rms, 14.63 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
2.022 ps rms, 20.22 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.762 ps rms, 17.62 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.821 ps rms, 18.21 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.260 ps rms, 12.60 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.432 ps rms, 14.32 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.336 ps rms, 13.36 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.182 ps rms, 11.82 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.234 ps rms, 12.34 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.219 ps rms, 12.19 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.154 ps rms, 11.54 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.159 ps rms, 11.59 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.333 ps rms, 13.33 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.212 ps rms, 12.12 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.228 ps rms, 12.287 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1.354 ps rms, 13.54 ps pk-pk, <10 ns pulse width, 10 mV/div, amplitude = 80% FS
1.235 ps rms, 12.35 ps pk-pk, <10 ns pulse width, 50 mV/div, amplitude = 80% FS
1.241 ps rms, 12.41 ps pk-pk, <10 ns pulse width, 100 mV/div, amplitude = 80% FS
1–39
