Tektronix MSO70000 Series Technical Reference page 33

Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
20 GS/s
Input
Frequency
10 MHz
510 MHz
1010 MHz
1510 MHz
2010 MHz
2510 MHz
10 GS/s
Input
Frequency
10 MHz
510 MHz
1010 MHz
1510 MHz
2010 MHz
2510 MHz
DPO7254
Enhanced bandwidth
40 GS/s
Input
Frequency
10 MHz
510 MHz
1010 MHz
1510 MHz
2010 MHz
2510 MHz
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Analog bandwidth setting
2.5 GHz 0.5 GHz
5.9 bits 6.3 bits
5.8 bits 6.3 bits
5.6 bits
5.6 bits
5.2 bits
4.6 bits
Analog bandwidth setting
2.5 GHz 0.5 GHz
5.9 bits 6.3 bits
5.8 bits 6.3 bits
5.6 bits
5.7 bits
5.7 bits
5.5 bits
Analog bandwidth setting
2.5 GHz 2.0 GHz
6.2 bits 6.4 bits
6.1 bits 6.3 bits
5.9 bits 6.1 bits
6.1 bits 6.4 bits
6.1 bits 6.3 bits
5.6 bits
0.25 GHz 0.02 GHz
6.5 bits 6.6 bits
0.25 GHz 0.02 GHz
6.5 bits 6.6 bits
1.0 GHz 0.5 GHz
6.9 bits 7.2 bits
6.9 bits 7.2 bits
6.9 bits
1–17
