Tektronix MSO70000 Series Technical Reference page 61

Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Logic and state trigger, minimum
timing requirements, typical
<4 GHz models
Logic type
State type
Time qualified logic type
Video-type trigger formats and field
rates,
<4 GHz models
Timeout trigger, minimum timing
requirements,
≥4 GHz models
Timeout type
Logic qualified timeout type
Timeout trigger, minimum timing
requirements,
<4 GHz models
Timeout type
Logic qualified timeout type
Window trigger, minimum timing
requirements,
≥ 4 GHz models
Window enters
Window exits
Logic qualified window enters
Logic qualified window exits
Window inside >t
Window outside >t
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Minimum duration of logic state: 100 ps (10 GB/s). The minimum duration of the logic pattern
includes delay mismatch between channels.
Minimum pulse width
100 ps (10 GB/s)
500 ps
300 ps
Triggers from negative sync composite video, field 1 or field 2 for interlaced systems, any
field, specific line, or any line for interlaced or non-interlaced systems. Supported systems
include NTSC, PAL, SECAM, and HDTV 1080/24sF, 1080p/25, 1080i/50, 1080i/60, 1080p/24,
720p/60, 480p/60.
Timeout event occurs after the signal has stayed in some state the minimum amount of time.
Setup and hold times are how long before and after the timeout event the logic level must
remain valid in order to generate a trigger.
Minimum pulse
width
N.A.
N.A.
Timeout event occurs after the signal has stayed in some state the minimum amount of time.
Setup and hold times are how long before and after the timeout event the logic level must
remain valid in order to generate a trigger.
Maximum ignored
pulse width
300 ps
300 ps
Minimum pulse
width
150 ps
500 ps
150 ps
500 ps
N.A.
N.A.
Rearm time
100 ps
500 ps
500 ps
Minimum rearm Setup time
time
300 ps + pulse N.A.
width
300 ps + pulse 50 ps
width
Minimum rearm Setup time
time
500 ps + pulse N.A.
width
500 ps + pulse 200 ps
width
Minimum rearm
Setup time
time
500 ps N.A.
150 ps N.A.
500 ps N.A.
150 ps N.A.
500 ps N.A.
150 ps N.A.
Hold time
N.A.
50 ps
Hold time
N.A.
200 ps
Hold time
N.A.
N.A.
N.A.
N.A.
N.A.
N.A.
1–45
