Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)

Table 3-11: Delta time measurement settings

Instrument Volts/div
BWE off
MSO72004C and 10 mV
DPO72004C, BWE
50 mV
off
100 mV
MSO71604C and 10 mV
DPO71604C, BWE
50 mV
off
100 mV
MSO71254C and 10 mV
DPO71254C, BWE
50 mV
off
100 mV
10 mV
MSO70804 and
DPO70804B, BWE
50 mV
off
100 mV
MSO70604 and 10 mV
DPO70604B, BWE
50 mV
off
100 mV
10 mV
MSO70404 and
DPO70404B, BWE
50 mV
off
100 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
c. Modify the initialized front-panel control settings:
Readjust the Trigger Level knob so the trigger level is at 50% of the
rising edge of the sine wave.
From the button bar, touch the Horiz/Acq button. Select the Manual
button to turn on Manual Mode.
Select the Acquisition tab. Press the IT button to turn on Interpolate
Time Only.
From the button bar, touch the Vertical button.
Select Analog Only.
Set the vertical scale, record length, and sample rate as indicated in
the following table.
Sine wave
generator Record Sample
frequency length rate
9.94 GHz 10000 500 GS/s
9.94 GHz 10000 500 GS/s
9.94 GHz 10000 500 GS/s
9.94 GHz 10000 500 GS/s
10000
9.94 GHz 500 GS/s
9.94 GHz 10000 500 GS/s
7.76 GHz 10000 500 GS/s
7.76 GHz 10000 500 GS/s
7.76 GHz 10000 500 GS/s
10000
4.97 GHz 500 GS/s
4.97 GHz 10000 500 GS/s
4.97 GHz 10000 500 GS/s
3.73 GHz 10000 500 GS/s
3.73 GHz 10000 500 GS/s
3.73 GHz 10000 500 GS/s
10000
2.48 GHz 500 GS/s
2.48 GHz 10000 500 GS/s
2.48 GHz 10000 500 GS/s
Burst Delta time rms
width accuracy limit
10 ns 1.280 ps
10 ns 1.172 ps
10 ns 1.186 ps
10 ns 1.280 ps
10 ns 1.172 ps
10 ns 1.186 ps
10 ns 1.304 ps
10 ns 1.201 ps
10 ns 1.205 ps
10 ns 1.462 ps
10 ns 1.295 ps
10 ns 1.336 ps
10 ns 1.625 ps
10 ns 1.427 ps
10 ns 1.463 ps
10 ns 2.022 ps
10 ns 1.762 ps
10 ns 1.821 ps
Delta time
pk-pk
accuracy limit
12.80 ps
11.72 ps
11.86 ps
12.80 ps
11.72 ps
11.86 ps
13.04 ps
12.01 ps
12.05 ps
14.62 ps
12.95 ps
13.36 ps
16.25 ps
14.27 ps
14.63 ps
20.22 ps
17.62 ps
18.21 ps
3–81
