Tektronix MSO70000 Series Technical Reference page 62

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Window trigger, minimum timing
requirements,
<4 GHz models
Window
Logic qualified window
Transition trigger, minimum timing
requirements, ≥4 GHz models
Transition type
Logic qualified transition type
Transition trigger, minimum timing
requirements, <4 GHz models
Transition type
Logic qualified transition type
Transition trigger, delta time range
Setup/Hold violation trigger, setup
and hold time ranges
Setup time
Hold time
Setup + hold time
Setup/hold time violation trigger,
minimum clock pulse widths, typical
≥ 4 GHz models
< 4 GHz models
1–46
Minimum pulse
width
225 ps
190 ps
The transition trigger event occurs at the end of the transition. The logic condition must be
valid at the moment the transition event occurs minus the setup time plus the hold time. Rearm
time is the time below the lower threshold and the time above the upper threshold. Neither
time can be violated.
Minimum pulse
width
0 ps
0 ps
The transition trigger event occurs at the end of the transition. The logic condition must be
valid at the moment the transition event occurs minus the setup time plus the hold time.
Minimum pulse
width
0 ps
330 ps
1 ns to 1 s
Minimum
-100 ns
-1 ns
500 ps
Minimum time from active clock edge to
inactive edge
Hold times ≥ 0: Hold time + 550 ps
Hold times <0: Hold time + 1.6 ns
Hold times ≥ 0: Hold time + 500 ps
Hold times <0: Hold time + 1.5 ns
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Minimum rearm Setup time
time
300 ps N.A.
300 ps -20 ps
Minimum rearm Setup time
time
500 ps N.A.
500 ps 50 ps
Minimum rearm Setup time
time
225 ps N.A.
225 ps 225 ps
Maximum
100 ns
102 ns
Minimum time from inactive clock edge to
active edge
500 ps
500 ps
500 ps
Hold time
N.A.
0 ps
Hold time
N.A.
50 ps
Hold time
N.A.
175 ps
