Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
21. Cable, Coaxial (three
required)
22. Adapter
23. Adapter
24. Adapter
25. Termination
26. Attenuator, 2X
27. Digital Multimeter
28. Cable, coaxial
29. Mouse or keyboard
30. Probe tip adapter
31. Logic probe
1 Fluke 9500B/1100, 9500B/3200, or 9500B/2200 and an output head (9510 or 9530) appropriate for the bandwidth of the instrument being tested.
2 For Delta Time Measurement Accuracy, use a Fluke 9500B or a pulse generator with the specified rise time. (See Table 3-10 on page 3-78.)
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Minimum requirements
50 Ω, 20 in, male-to-male
SMA connectors
SMA "T", male to 2 SMA
female
SMA female to BNC male
BNC male to female elbow
Short circuit, SMA connector,
female
Ratio: 2X; impedance 50 Ω;
connectors: female BNC
input, male BNC output
Ohms: <60 Ohms
50 Ω, 39.37 in (1.0 m),
male-to-male SMA connectors
50 Ω, 60 in (1.5 m),
male-to-male SMA connectors
BNC female to square pin
adapter, 50 Ω
P6717 or P6780 Logic Probe
Example
Tektronix part number
174-1427-00
Tektronix part number
015-1016-00 (18 GHz)
Tektronix part number
015-0572-00 (4 GHz)
Tektronix part number
103-0031-00
Tektronix part number
015-1021-00 (18 GHz)
Tektronix part number
011-0069-02 (2 GHz)
Keithley 2700
Tektronix part number
174-1341-00
Tektronix part number
174-1428-00
Tektronix part numbers:
119-6298-xx (mouse)
119-6297-xx (keyboard)
Tektronix part number
067–1734–00
Tektronix part P6717 or
P6780
Purpose
Used to test delta time
measurement accuracy,
probe compensation out,
trigger sensitivity
Used to test delta time
measurement accuracy
Used to test delta time
measurement accuracy and
trigger sensitivity
Used to test delta time
measurement accuracy
Used to test delta time
measurement accuracy
Used to test delta time
measurement accuracy,
pulse trigger accuracy, time
qualified trigger, trigger
sensitivity, and channel
isolation
Checking input impedance
Checking analog bandwidth
and delta time measurement
accuracy. Checking ≥ 4 GHz
models serial trigger baud
rate limits
Used to input test selections
Checking digital channels
Checking digital channels
