Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-2: Horizontal and acquisition system specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000
Series models
Characteristic
Real-time sample rate range
MSO70804, MSO70604,
MSO70404,
DSA70804B, DSA70604B,
DSA70404B,
DPO70804B, DPO70604B,
DPO70404B
MSO72004C, MSO71604C,
MSO71254C, DSA72004C,
DSA71604C, DSA71254C,
DPO72004C, DPO71604C,
DPO71254C
DPO7354 and DPO7254
DPO7104
DPO7054
Equivalent-time sample rate or
interpolated waveform rate range
≥ 4 GHz models
< 4 GHz models
Maximum record length, sample
mode,
≥ 4 GHz models
1–34
Description
Number of channels acquired
All channels
All channels
Two channels
1
2
3 or 4
1
2
3 or 4
1
2
3 or 4
Equivalent-time acquisition can be enabled or disabled. When disabled, waveforms are
interpolated at the fastest time base settings.
Up to 5 TS/s and 0.2 ps trigger placement resolution
Up to 4 TS/s
The maximum record length depends on the installed record length options. Maximum record
length is less in serial trigger mode, hi-res mode, or when using the FIR filter.
Standard on MSO70000/C Series,
DSA70000B/C Series, and DPO70000B/C
Series
Option 2XL installed, standard on
DSA70000/B Series
Option 5XL installed
Option 10XL installed
Option 20XL installed
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Sample rate, maximum
(Standard) (Option 2SR)
Up to 25 GS/s
Up to 50 GS/s
Up to 100 GS/s
40 GS/s
20 GS/s
10 GS/s
20 GS/s
10 GS/s
5 GS/s
10 GS/s 20 GS/s
5 GS/s 10 GS/s
2.5 GS/s 5 GS/s
12,500,000 points
31,250,000 points
62,500,000 points (all channels)
125,000,000 points (all channels)
250,000,000 points (all channels)
