Performance Verification (MSO/DPO5000 Series)
DC Gain Accuracy
Performance
checks Bandwidth
Channel 2 DC 20 MHz
Gain Accuracy,
0 V offset, 0 V
vertical position,
50 Ω
20 MHz
Channel 2 DC
Gain Accuracy,
0 V offset, 0 V
vertical position,
1 MΩ
250 MHz
FULL
4–8
Vertical scale
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
63.5 mV/div
100 mV/div
200 mV/div
500 mV/div
1 V/div
20 mV/div
20 mV/div
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Low limit Test result
-2.0%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
-2.0%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
-3.0%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
-1.5%
High limit
2.0%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
2.0%
1.5%
1.5%
1.5%
1.5%
1.5%
3.0%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
