Tektronix MSO70000 Series Technical Reference page 45

Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.)
20 GS/s
Step gain
500 mV
200 mV
100 mV
50 mV
20 mV
10 mV
5 mV
2 mV
1 mV
10 GS/s
Step gain
500 mV
200 mV
100 mV
50 mV
20 mV
10 mV
5 mV
2 mV
1 mV
Without enhanced bandwidth
40 GS/s
Step gain
500 mV
200 mV
100 mV
50 mV
20 mV
10 mV
5 mV
2 mV
1 mV
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
2.5 GHz 2.0 GHz
19.5 mV 16.1 mV
8.7 mV 7.05 mV
5.15 mV 4.2 mV
2.0 mV 1.65 mV
0.855 mV 0.71 mV
0.515 mV 0.42 mV
0.34 mV 0.345 mV
0.135 mV 0.135 mV
0.095 mV 0.095 mV
2.5 GHz 2.0 GHz
20.2 mV 16.7 mV
8.9 mV 7.3 mV
5.3 mV 4.3 mV
2.1 mV 1.7 mV
0.88 mV 0.74 mV
0.52 mV 0.43 mV
0.345 mV 0.33 mV
0.135 mV 0.135 mV
0.095 mV 0.095 mV
2.5 GHz 0.5 GHz
22.7 mV 16.4 mV
9.84 mV 6.97 mV
5.89 mV 3.74 mV
2.31 mV 1.69 mV
0.964 mV 0.697 mV
0.574 mV 0.379 mV
0.4 mV 0.231 mV
0.19 mV 0.195 mV
0.12 mV 0.12 mV
1.0 GHz 0.5 GHz
12.0 mV 9.8 mV
5.1 mV 4.0 mV
2.95 mV 2.35 mV
1.25 mV 1.05 mV
0.52 mV 0.425 mV
0.295 mV 0.235 mV
0.21 mV 0.155 mV
0.135 mV 0.135 mV
0.095 mV 0.095 mV
1.0 GHz 0.5 GHz
12.5 mV 10.3 mV
5.3 mV 4.16 mV
3.05 mV 2.4 mV
1.3 mV 1.1 mV
0.55 mV 0.435 mV
0.3 mV 0.24 mV
0.21 mV 0.155 mV
0.135 mV 0.135 mV
0.095 mV 0.095 mV
0.25 GHz 0.02 GHz
15.0 mV 14.5 mV
6.2 mV 5.8 mV
3.2 mV 2.9 mV
1.55 mV 1.45 mV
0.63 mV 0.59 mV
0.325 mV 0.295 mV
0.175 mV 0.145 mV
0.12 mV 0.065 mV
0.12 mV 0.045 mV
1–29
