Callout
Description
2
Power supply backplane board
3
SP card
4
System battery
5
PCIe NVMe Switch card
6
HBA card
7
CPU
8
Heatsink
9
Cover
10
Memory riser card
Component Designations
This section describes the naming designations for internal and external slots:
"Fan Module Slot Designations" on page 73
■
"CPUs and Memory Riser Card Slots Designations" on page 74
■
"DIMM Slot Designations" on page 75
■
"Power Supply Designations" on page 76
■
"PCIe Slot Designations" on page 77
■
"DVD, Storage Drive, and USB Designations" on page 78
■
Fan Module Slot Designations
The six fan module slots are at the front of the server and are set in two rows of three slots. The
slots are designated from left to right. As pictured in the illustration below, the three front row
slots are designated as: FM0, FM1, and FM2. The three back row slots are: FM3, FM4, and
FM5.
Component Serviceability, Locations, and Designations
Callout
Description
12
Motherboard
13
Storage drive
14
DVD drive
15
Fan module
16
Fan board
17
Storage drive backplane board
18
Server chassis
19
ESM (Energy Storage Module for
HBA)
Servicing the Server
73
