Memory Riser Card And Dimm Reference - Oracle X5-4 Service Manual

Install a Memory Riser Card

Memory Riser Card and DIMM Reference

The following sections contain information about memory riser cards and DIMMs:
"Memory Riser Card Components" on page 154
■
"Memory Riser Cards Physical Layout" on page 155
■
"Memory Riser Card Population Rules" on page 156
■
"Supported DIMMs and DIMM Population Rules" on page 157
■
"Troubleshooting a Multi-DIMM Failure State" on page 159
■
Memory Riser Card Components
The following illustration shows the components of the memory riser card.
Callout
1
154 Oracle Server X5-4 Service Manual • December 2015
Description
Connector
Callout Description
5 DIMM ejector/locking levers (two on
each slot)
