Turn On The Locator Indicator Remotely (Oracle Ilom Web Interface) - Oracle X5-4 Service Manual

Turn On the Locator Indicator Remotely (Oracle
ILOM Web Interface)
The Locator indicator helps you identify the a specific server in a rack.
1. Log in to the Oracle ILOM web interface.
To log in, open a web browser and direct it using the IP address of the server SP. Log in as root
or a user with administrator privileges. For more information, refer to the Oracle X5 Series
Servers Administration Guide at http://www.oracle.com/goto/x86AdminDiag/docs.
The Summary screen appears.
2. In the Actions section, verify that the Locator indicator is off, and then click the
Turn On button.
3. Click OK.

Turn On the Locator Indicator Remotely (Oracle ILOM Web Interface)

Preparing to Service the Server 109
