Remove an NVMe Storage Drive From the Server

Remove an NVMe Storage Drive From the Server
Perform this procedure to physically remove an NVMe storage drive from the server.
Identify the location of the NVMe drive that you want to remove.
1.
For storage drive locations, see
Verify that the blue OK to Remove indicator on the NVMe drive is lit.
2.
Refer to
3. On the NVMe drive you plan to remove, push the latch release button to open the
drive latch.
See "Remove a Storage Drive (CRU)" on page
4. Grasp the latch and pull the drive out of the drive slot.
5. Consider your next steps:
If you are replacing the drive, continue to
■
Drive" on page
If you are not replacing the drive, install a filler panel in the empty drive slot to maintain
■
proper airflow and perform administrative tasks to configure the server to operate without
the drive.
For information on how to install a storage drive filler panel, see
Filler Panel (CRU)" on page

Verify Removal of an NVMe Storage Drive

Verify that the NVMe drive has been removed. Type:
#
lspci -nnd :0953
This commands returns output similar to the following:
# lspci -nnd :0953
13:00.0 Non-Volatile memory controller [0108]: Intel Corporation Device [8086:0953] (rev
01)
14:00.0 Non-Volatile memory controller [0108]: Intel Corporation Device [8086:0953] (rev
01)
15:00.0 Non-Volatile memory controller [0108]: Intel Corporation Device [8086:0953] (rev
01)
128 Oracle Server X5-4 Service Manual • December 2015
"DVD, Storage Drive, and USB Designations" on page 78
"Prepare an NVMe Storage Drive for Removal" on page
128.
119.
126.
115.
"Verify Removal of an NVMe Storage
"Install a Storage Drive
