NVMe Storage Drive Virtual PCIe Slot Designation

If NVMe storage drives are installed, they are labeled on the system front panel as NVMe0,
NVMe1, NVMe2, and NVMe3. However, the server BIOS internally identifies these drives
by their virtual PCIe slot numbers. When using operating system commands to power NVMe
drives off before removal, you need to know the virtual PCIe slot number of the drive.
The following table lists the drive front panel label and its corresponding virtual PCIe slot
number used by the operating system.
Front Panel Storage Drive Label
NVMe0
NVMe1
NVMe2
NVMe3

Remove a Storage Drive Filler Panel (CRU)

For information about component filler panels, see
1. Prepare the server for service.
See "Preparing to Service the Server" on page
2. If necessary, press the Locator indicator button to deactivate the indicator.
3. Identify the storage drive filler panel you want to remove.
4. Push the release button to open the latch.
To remove the filler panel, use the latch to pull the filler panel out of the slot.
5.

Remove a Storage Drive (CRU)

Use this procedure to remove a storage drive from the server.
For serviceability considerations, see
Before You Begin ■

Remove a Storage Drive Filler Panel (CRU)

Virtual PCIe Slot Number
PCIe slot 100
PCIe slot 101
PCIe slot 102
PCIe slot 103
"Component Filler Panels" on page
93.
"Component Serviceability" on page
Servicing CRU Components
81.
70.
115
