Servicing Fan Modules (CRU)

2. Confirm that the drive has been enabled and is seen by the system.
Do one of the following:
Check the /var/log/messages log file.
■
List available NVMe devices. Type:
■
#
ls -l /dev/nvme*
Related Information
"Storage Drive Reference" on page 119
■
"Storage Drives Hot-Plug Conditions" on page 114
■
"Storage Drive Failure and RAID" on page 114
■
"DVD, Storage Drive, and USB Designations" on page 78
■

Servicing Fan Modules (CRU)

This section provides instructions for removing and installing a fan module.
"Remove a Fan Module" on page 130
■
"Install a Fan Module" on page 133
■
"Fan Module Reference" on page 135
■

Remove a Fan Module

Fan modules provide server cooling to the motherboard and its components. The fan modules
are arranged in stacked pairs (a front row and a back row) to provide redundancy. If you remove
a fan module, replace it immediately.
Fan modules are hot-serviceable components. It is not necessary to power off the server
or to remove the server cover to service a fan module. However, depending on server rack
configuration, it might be necessary to partially extend the server from the rack to access the
fan modules. (Optional steps for partially extending the server from the rack are included in
this procedure.) Take care when partially extending the server from the rack during hot service.
Ensure that the cables at the back of the server do not become dislodged, particularly the power
cables. As an option, you can also perform this procedure using cold service.
For serviceability considerations, see
Before You Begin ■
For fan module designation information, see
■
130 Oracle Server X5-4 Service Manual • December 2015
.
"Component Serviceability" on page
"Component Designations" on page
70.
73.
