Refer to the figure in step 4 to determine proper connections.
Note -
the disk backplane area.
11.
Reinstall the P0 MR0/MR1 memory risers you removed earlier.
See
"Install a Memory Riser Card" on page
Prepare the server for operation.
12.
See
"Prepare the Server for Operation" on page
Replace the Fan Board (FRU)
This section provides instructions for replacing the fan board.
When servicing the components in this section, unplug the AC power cords and use ESD
protection.
For serviceability considerations, see
Before You Begin
Prepare the server for service.
1.
See
"Prepare the Server for Cold Service" on page
2.
Remove all fan modules.
See
"Remove a Fan Module" on page
3.
Remove all memory risers.
See
"Remove a Memory Riser Card" on page
Any excess cable length should be in the PCIe card area to allow better air flow through
152.
259.
"Component Serviceability" on page
94.
130.
145.
Replace the Fan Board (FRU)
70.
Servicing FRU Components
221
