Oracle X5-4 Service Manual page 131

1. Prepare the server:
For hot service, see
■
For cold service, see
■
2. If necessary, slide the server partially out from the rack.
a. At the back of the server, verify that the cables have sufficient length and
clearance to extend the server.
The cable management arm (CMA) that is supplied with the server is hinged to facilitate
extending the server to the maintenance position. However, ensure that the cables do not
impede the sliding movement and are not damaged or overextended by it.
b. At the front of the server, release the slide rails by pushing the two green
latches inward.
Identify the faulty fan module using the fan module indicators.
3.
"Prepare the Server for Hot Service" on page
"Prepare the Server for Cold Service" on page
Remove a Fan Module
93.
94.
Servicing CRU Components 131
