Manage the Locator Indicator Locally

The Locator indicator on the Summary screen changes to indicate the status of the Locator
indicator.
Oracle Integrated Lights Out Manager 3.2.x Documentation Library at:
See Also ■
oracle.com/goto/ILOM/docs
Manage the Locator Indicator Locally
Once you have identified the server by its blinking Locator indicator, use this procedure to turn
off the Locator indicator.
You must be physically present at the server.
Before You Begin ■
For button and indicator location information, see
■
Features" on page
To manage the Locator indicator locally, do one of the following:
To turn the Locator indicator off, press the Locator indicator button.
■
To turn on the Locator indicator, press the Locator indicator button.
■
Note -
locally, as part of a physical presence verification step.
To perform a lamp test of all front panel indicator LEDs, press the Locator
■
indicator three times within a five-second period.
All of the front panel LEDs light up and remain lit for 15-20 seconds.
Oracle Integrated Lights Out Manager 3.2.x Documentation Library at:
See Also ■
oracle.com/goto/ILOM/docs

Remove the Server Cover

This section provides instructions for removing the server cover.
The server cover has an interlock switch which is a safety mechanism that prevents power from
being applied to the server when the cover is off. The switch prevents accidental contact with
110 Oracle Server X5-4 Service Manual • December 2015
17.
Some Oracle ILOM security procedures require that you turn on the Locator indicator
http://www.
"Server Front Panel
http://www.
