Any excess cable length should be in the PCIe card area to allow better air flow through
Note -
the disk backplane area.
11. Reinstall the P0 MR0/MR1 memory risers you removed earlier.
See "Install a Memory Riser Card" on page
12. Prepare the server for operation.
See "Prepare the Server for Operation" on page
Replace the SAS 12 Gb/s Internal HBA ESM Cable
(FRU)
Prepare the server for service.
1.
See "Prepare the Server for Cold Service" on page
2. Disconnect the ESM cable from the HBA card in PCIe slot 2 and the ESM module.

Replace the SAS 12 Gb/s Internal HBA ESM Cable (FRU)

152.
259.
94.
Servicing FRU Components 209
