Assign Serial Port Ownership Using the Web Interface
Set up a network connection to the SP before attempting to change the serial port owner to the
Before You Begin
host server. If the network is not set up, and you switch the serial port owner to the host server,
you will be unable to connect using the CLI or web interface to change the serial port owner
back to the SP.
To return the serial port owner setting back to the SP, use the network connection to Oracle
ILOM.
1. Log in to the service processor Oracle ILOM web interface.
To log in, open a web browser and direct it using the IP address of the server SP. Log in as root
or a user with administrator privileges. Refer to the Oracle X5 Series Servers Administration
Guide at http://www.oracle.com/goto/x86AdminDiag/docs.
The Summary screen appears.
2. In the ILOM web interface, select ILOM Administration --> Connectivity from the
navigation menu on the left side of the screen.
3. Select the Serial Port tab.
The Serial Port Settings page appears.
Note -
4.
To set the host as the serial port owner, select Host Server at the Serial Port
page.
5.
To set the SP as the serial port owner, select Service Processor at the Serial Port
page.
6.
Click Save for the changes to take effect.
7. Log out of Oracle ILOM.

Resetting the Host or Service Processor

This section provides procedures for resetting the host and the SP
The serial port sharing setting by default is Service Processor.
Assign Serial Port Ownership Using the Web Interface
Troubleshooting and Diagnostics 63
