b. Align the two tabs on the divider with the two slots in the power supply side
wall.
c. Push the tabs into the slots so that the air divider is flush with the power
supply side wall.
d. Then, slide the air divider downward to lock the tabs in the slots and secure
it against the wall.
To ensure proper alignment of the Fault Remind switch, both tabs must be engaged with
their slots.
30. Reconnect the SAS cables and NVMe cables (if installed) to the disk backplane.
See "Replace the SAS 12 Gb/s Internal HBA SAS Cables (FRU)" on page 204
the NVMe Switch Card Cables (FRU)" on page
31. Reconnect the ESM cable to the ESM.
See "Replace the SAS 12 Gb/s Internal HBA ESM Cable (FRU)" on page
Or, if you removed the ESM, reattach it to the dual lock strip on the chassis.
32. Reinstall the memory risers.
See "Install a Memory Riser Card" on page
For a two-CPU system, install the air baffle.
33.
The air baffle simply drops into place using existing memory riser guides.
34. Install all PCIe cards.
See "Install a PCIe Card" on page
When reinstalling the HBA card and NVMe switch card (if installed), it might be easier
Note -
to reconnect the SAS/SATA and NVMe cables before installing the cards their PCIe slots.
35. Install the power supplies.
See "Install a Power Supply" on page
Prepare the server for operation.
36.
See "Prepare the Server for Operation" on page
Replace the Power Supply Backplane Board (FRU)
215.
152.
164.
138.
259.
and "Replace
209.
Servicing FRU Components 237
