Caution -
cause the server to over heat. Install only the supported model.
For serviceability considerations, see
Before You Begin
■
For power supply designation information, see
■
Ensure that the replacement power supply handle is in the open position.
1.
2.
Align the power supply with the empty power supply bay.
3.
Slide the power supply into the bay until it stops.
4.
To seat the power supply, rotate the release handle upward until it locks in place.
Note -
supply bay.
This action of rotating the handle upward draws the power supply into the server and engages it
with the internal connector.
5.
Connect the AC power cord to the power supply.
6.
Reattach the power cord retaining clip.
System overheat and shut down. Installing the incorrect model of power supply can
The pawl at the hinge of the handle must engage the slot at the bottom of the power
"Component Serviceability" on page
"Component Designations" on page
Servicing CRU Components
Install a Power Supply
70.
73.
139
