Component Serviceability, Locations, and Designations
Callout
1
2
3
4
5
6
Power Supply Designations
The two power supply slots are located on the right side of the server (from the front of the
server) and are designated from right to left. The slots are accessible from the back of the
server. From the back of the server, the left slot is designated as PS-0, and the right slot is PS-1.
76 Oracle Server X5-4 Service Manual • December 2015
Description
Slot D0
Slot D1
Slot D2
Slot D3
Slot D4
Slot D5
Callout Description
7 Slot D6
8 Slot D7
9 Slot D8
10 Slot D9
11 Slot D10
12 Slot D11
