Prepare the Server for Cold Service

This procedure uses the Oracle ILOM web interface. However, the procedure can also be
■
performed using the Oracle ILOM CLI. For more information, refer to the Oracle ILOM
documentation.
1. Log in to the Oracle ILOM web interface.
To log in, open a web browser and direct it using the IP address of the server SP. Log in as root
or a user with administrator privileges. For more information, refer to the Oracle X5 Series
Servers Administration Guide at http://www.oracle.com/goto/x86AdminDiag/docs.
The Summary screen appears.
2. In the Actions section of the Summary screen, click the Locator Indicator Turn
On button.
This action activates the Locator indicator on the server front panel. For more Locator indicator
management options, see
3. Once at the server, press the Locator indicator button to deactivate the indicator.
See "Manage the Locator Indicator Locally" on page
4. Set up an ESD-safe space at the service location.
See "Performing Electrostatic Discharge and Static Prevention Measures" on page
The following components can be hot-serviced:
Next Steps
"Servicing Storage Drives (CRU)" on page 113
■
"Servicing Fan Modules (CRU)" on page 130
■
"Servicing Power Supplies (CRU)" on page 137
■
Prepare the Server for Cold Service
Note -
However, the procedure can also be performed using only the Oracle ILOM CLI interface.
For more information about the Oracle ILOM CLI interface, refer to the Oracle ILOM
documentation.
A cold-service component must be serviced when the server is completely powered off. For
more information about component serviceability, see
This procedure describes how to prepare the server for service, so you can:
94 Oracle Server X5-4 Service Manual • December 2015
"Managing the Locator Indicator" on page
This procedure uses a combination of the Oracle ILOM web and CLI interfaces.
107.
110.
"Component Serviceability" on page
79.
70.
