Turn On the Locator Indicator Remotely (Oracle ILOM Web Interface)

Turn On the Locator Indicator Remotely (Oracle
ILOM Web Interface)
Before going to the server, activate the server Locator indicator. This allows you to identify the
correct server within the rack.
Log in to the service processor Oracle ILOM web interface.
1.
To log in, open a web browser and direct it using the IP address of the server SP. Log in as root
or a user with administrator privileges. For more information, see
Administration Guide
The Summary screen appears.
2. In the Actions section, verify that the Locator indicator is off, and then click the
Turn On button.
3. Click OK.
The Locator indicator on the Summary screen changes to indicate the status of the Locator
indicator.
"Performing Electrostatic Discharge and Static Prevention Measures" on page 74
■
Next Steps
■ Oracle Integrated Lights Out Manager 3.2 Documentation Library at:
com/goto/ILOM/docs

Manage the Locator Indicator Locally

Once you have identified the server by its blinking Locator indicator, use this procedure to turn
off the LED.
Use this procedure to turn the Locator indicator off and on when local to the server.
You must be physically present at the server.
■
Before You Begin
For button and indicator location information, see
■
Features" on page
To manage the Locator indicator locally, do one of the following:
■ To turn off the blinking LED, press the Locator indicator button.
■ To turn on the Locator indicator, press the Locator indicator button.
106 Sun Server X4-4 Service Manual • October 2015
.
19.
Oracle X4 Series Servers
http://www.oracle.
"Server Front Panel
