1-16 DS20E Reference Guide

Memory

Part Number: ER-K8F6W-UA .A01 File Name: b-ch1 System Overview.doc Last Saved On: 10/4/99 1:23 PM
The system supports up to four banks of memory on the system board. Each
bank contains four slots with a total of 16 slots on the system board. The
system uses 200 pin buffered synchronous Dual In-Line Memory Module
(DIMMs).
Table 1-5 illustrates an example of typical SDRAM configurations.
Typical SDRAM Configurations
Array 0 Array 1
32MB x 4 32MB x 4
32MB x 4 32MB x 4
32 MB x 4 64 MB x 4
64MB x 4 64MB x 4
64MB x 4 64MB x 4
128MB x 4 128MB x 4
128MB x 4 128MB x 4
256 MB x 4 128 MB x 4
256MB x 4 256MB x 4
256MB x 4 256MB x 4
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: DS20E Reference Guide Comments:
Table 1-5
Array 2 Array 3
32MB x 4 32MB x 4
64 MB x4
64MB x 4 64MB x 4
128MB x 4 128MB x 4
256MB x 4 256MB x 4
Total
256MB
512MB
640 MB
512MB
1GB
1GB
2GB
1.5 GB
2GB
4GB
