Power Requirements

Your system automatically detects the voltage source when you power up the
system, and adjusts the power supply input to accept that voltage. Figure 2-2
shows the power supply requirements.
100-120VAC 7.0A 50/60 Hz
220-240VAC 3.0A 50/60 HZ
Figure 2-2. Power Supply Requirements
NOTE:
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: DS20E Reference Guide Comments:
Part Number: ER-K8F6W-UA .A01 File Name: c-ch2 Installing The Proliant Alpha 2P Server.doc Last Saved On: 9/30/99 3:58 PM
1. Current ratings are maximum with a fully loaded system
and do not include a monitor or terminal.
2. See Appendix D for information on specific power supply
ratings.
Installing the Pedestal 2-3
