Grounding Methods

Part Number: ER-K8F6W-UA. A01 File Name: n-appb.doc Last Saved On: 10/4/99 11:26 AM
There are several methods for grounding. Use one or more of the following
methods when handling or installing electrostatic-sensitive parts:
Use a wrist strap connected by a ground cord to a grounded system
chassis. Wrist straps are flexible straps with a minimum of 1 megohm ±
10 percent resistance in the ground cords. To provide proper ground,
wear the strap snug against the skin.
Use heel straps, toe straps, or boot straps at standing servers. Wear the
straps on both feet when standing on conductive floors or dissipating
floor mats.
Use conductive field service tools.
Use a portable field service kit with a folding static-dissipating
work mat.
If you do not have any of the suggested equipment for proper grounding, have
an Authorized Compaq Reseller install the part.
NOTE: For more information on static electricity, or assistance with product
installation, contact your Authorized Compaq Reseller.
