7-8 DS20E Reference Guide
Backplane Connector
Figure 7-4 6-Slot Backplane Drive Connectors
6-Slot SCSI ID Orientation
No.
J4
J5
J6
J7
J8
J9
1
2
3
4
5
6
SC0119
Table 7-3
Slot No.
SCSI ID
0
1
2
3
4
5
