5-10 DS20E Reference Guide

Determining the SCSI Storage Device ID

Part Number: FR-K8F6W-UA .A01 File Name: f-ch5 Reconfiguring the System.doc Last Saved On: 9/30/99 4:20 PM
The system is designed for plug and play which offers a jumperless
configuration of SCSI ID, automatic SCSI termination, and automatic system
recognition. The storage cage has a capacity of four 1.6-inch disk drives or six
1.0-inch disk drives which is pre-configured at the factory.
The SCSI ID for disk drives is preset on the backplane with the lowest ID to
the left for a vertically installed storage cage and from the bottom of a
horizontally installed cage. Table 5-2 shows the orientation of the SCSI IDs
for a vertically installed storage cage (both the 4-slot and 6-slot storage
subsystems).
4 or 6-Slot SCSI ID Orientation
Slot
1
2
3
4
5
6
NOTE: Tape devices added to the spare removable media bay must have their SCSI ID set
on the device to avoid conflict with other drives.
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
Table 5-2
SCSI ID
0
1
2
3
4
5
