3-20 DS20E Reference Guide

Stabilizing the Rack

Part Number: FR-K8F6W-UA .A01 File Name: d-ch3 Installing a Rack System.doc Last Saved On: 10/4/99 1:25 PM
Figure 3-13. Activating the Stabilizer Foot
The system is intended for installation in one of the following racks, which are
equipped with a stabilizer bar;
H9A10 M-Series Medium Rack
H9A15 M-Series Tall Rack
Pull out the stabilizer bar and extend the leveler foot to the floor before
installing the system.
If you are using a rack other than those listed above, install rack stabilizing
feet or provide other means to stabilize the rack before installing the system.
