Table 9-5 Hot-Swap Drive Status Leds - Compaq AlphaServer DS20E Reference Manual

Activity
Status
(Green)
Off
On
X
X
X
X
X
X
X
X
X
X
X
X
X
NOTE: The highest number priority is displayed when multiple conditions exist.
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
Part Number: ER-K8F6W-UA .A01 File Name: j-ch9 Troubleshooting.doc Last Saved On: 10/4/99 2:06 PM
Table 9-5
Hot-Swap Drive Status LEDs
Drive Fault Status
Power On (Amber)
(Green)
X X
X X
Off Off
On On
Slow Off
Off On
Fast Off
On Fast
Off Slow
Off On
Off Fast
Fast On
Fast Fast
On Off
Fast Slow
Troubleshooting 9-7
Priority Indication
- No drive activity.
- Drive being accessed.
0 Default.
1 Ready for removal.
2 Prepared for operation.
3 Device faulty.
4 Device rebuilding.
5 In failed array.
6 In critical array.
7 Parity check.
8 Predicted fault.
9 Unconfigured.
10 Hot spare.
11 Rebuild stopped.
12 Identify.
