Page 1 This manual provides installation and configuration instructions for the system management console, as well as information about using the system management console for managing consoles in Compaq AlphaServer GS80/160/320 systems. This manual is for service providers, managers, and operators of Compaq AlphaServer GS80/160/320 systems.
Page 2 Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is provided “as is” without warranty of any kind and is subject to change without notice.
Page 3 Japanese Notice Canadian Notice This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Avis Canadien Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. European Union Notice Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Page 5: Table Of Contents
Connecting the SMC in a System with Multiple Serial Console Lines Set Up the SMC ... 3-2 Cable the Terminal Server to the SMC... 3-4 Cable the Terminal Server to the GS80/160/320 ... 3-6 3.3.1 Make the Cable Connection ... 3-6 3.3.2 Record the Connections...
Page 6 Bind the Protocol ... 5-12 5.2.6 Verify the Network Setup ... 5-13 Enter the Mail Server Name in the ConsoleWorks Script... 5-14 Configure Outlook Express ... 5-16 Delete Unused Consoles in ConsoleWorks... 5-18 Configure the Terminal Server: Access Server Loader... 5-20 5.6.1...
Page 7 8.4.4 Renaming a Console... 8-20 Managing Events and Actions ... 8-22 8.5.1 Adding an Event ... 8-24 8.5.2 Importing and Using Compaq-Supplied Events ... 8-26 8.5.3 Enabling an Action ... 8-28 8.5.4 Adding a Scan ... 8-32 8.5.5 Acknowledging and Purging Events... 8-34 8.5.6...
Page 8 11.2 Changing Baud Rates: System with Multiple Console Lines ... 11-8 11.2.1 Set the Terminal Server Port Speed to Match the GS80/160/320 Partition Speed ... 11-8 11.2.2 Test for a Baud Rate Match and Set Both to 9600 ... 11-12 11.3...
Page 9 Remove the Existing Connection from the SMC System to the GS160/320 ...B-2 Attach the Mounting Brackets...B-4 Install the Terminal Server in the GS160/320 Power Cabinet ...B-6 Connect the Terminal Server to the Power Source...B-8 Cable the Terminal Server to the SMC System...B-10 Cable the Terminal Server to the GS160/320 ...B-12...
Page 10 System Management Console ... 1-2 3–1 GS80/160/320 Keyswitch... 3-2 3–2 Windows NT Security Window ... 3-2 3–3 Terminal Server Management Channel Connector ... 3-4 3–4 Network Adapter 2... 3-5 3–5 Local Port Location ... 3-6 3–6 Terminal Server Ports... 3-7 3–7...
Page 11 ConsoleWorks Delete Console Screen ... 5-18 5–13 Delete Console Verification Message ... 5-19 5–14 Access Server Loader Window ... 5-20 5–15 Access Server Loader Confirm Dialog Box... 5-21 5–16 Access Server Loader Configuration Dialog Box... 5-22 5–17 Location of Hardware Address Label... 5-23 5–18 Access Server Loader Window ...
Page 12 8–18 Event event_name Actions Screen... 8-29 8–19 Mail from ConsoleWorks... 8-30 8–20 Add Scan Screen... 8-32 8–21 Scan scan_name Screen ... 8-33 8–22 ConsoleWorks Events Detail Screen... 8-34 8–23 Acknowledged Event ... 8-35 8–24 Expunge Events Screen ... 8-36 8–25 Expunge Completed Message...
Page 13 Show Consoles Screen ... 11-16 11–9 LAN Settings Dialog Box – Automatic Configuration ... 11-18 11–10 LAN Settings Dialog Box – Proxy Server ... 11-19 11–11 ConsoleWorks Services ... 11-20 11–12 Service Dialog Box ... 11-21 11–13 Switch Setting for Models DPENM and DPEND... 11-22 11–14 System Properties Dialog Box...
Page 14 PCI Box Rear – Local Port Connection ...C-3 C–3 Mounting Brackets...C-4 C–4 Position Identifier Dial...C-6 C–5 Terminal Server Placement in the GS80 System ...C-7 C–6 GS80 AC Input Box...C-8 C–7 Terminal Server Management Channel Connector ...C-10 C–8 Network Adapter 2...C-11 C–9...
Page 15: Connecting The Smc In A System With Multiple Serial
Intended Audience This manual is for service providers, managers, and operators of Compaq AlphaServer GS80/160/320 systems. Document Structure This manual uses a structured documentation design. Topics are organized into small sections, usually consisting of two facing pages. Most topics begin with an abstract that provides an overview of the section, followed by an illustration or example.
Page 16: Alphaserver Gs80/160/320 Documentation
Chapter 8, ConsoleWorks, contains information about using the application to manage the GS80/160/320 consoles. Chapter 9, Compaq AlphaServer Partition Manager, contains directions for using this application to partition the GS80/160/320 system. Chapter 10, Graphical Configuration Utility, has information about setting up and using the utility.
Page 17: Information On The Internet
EK–GS320–RM AG–RKSZ*–BE EK–GSCON–IN EK–GS320–UP EK–GSR80–UP EK–GS320–SP Information on the Internet Visit Compaq’s AlphaServer site at www.compaq.com/alphaserver/ site_index.html for more information about AlphaServer GS80/160/320 systems. Title AlphaServer GS80/160/320 User Information CD (translations) AlphaServer GS80/160/320 Service Documentation Kit AlphaServer GS80/160/320 Service Manual...
Page 19: Part 1 Overview Of The System Management Console
Part 1 Overview of the System Management Console...
Page 21: Chapter 1 Overview
The system management console is the console device for AlphaServer GS80/160/320 systems. It consists of a Compaq Deskpro PC, a DECserver 90M terminal server, and associated hardware and software. Sections in this chapter include: System Management Console Overview How to Use This Manual...
Page 22: System Management Console Overview
Figure 1–1 System Management Console ConsoleWorks Screens (one for each partition) System Management Modem Console PC COMPAQ Modem Remote Service PC SMC Installation and User's Guide Corporate Network GS320 with 8 Partitions Partition Terminal Partition Server Partition Partition Private Partition Partition...
Page 23 LAN. The second connects to the corporate network, enabling remote operation of the system management console through a Web browser. The PC also has an attached modem, which can provide Compaq Services remote access to the GS80/160/320 system. ConsoleWorks...
Page 24: How To Use This Manual
How to Use This Manual The chapters and appendixes in this manual provide instructions for installing and using the system management console and for restoring the SMC disk. Installing the system management console – In Part 2 of this manual, Chapters 3 through 6 provide procedures for cabling and configuring the system management console.
Page 25: Part 2 Installing The System Management Console
Part 2 Installing the System Management Console...
Page 27: Chapter 2 Before You Begin
This chapter contains information you need before starting the installation. Sections in this chapter are: Installation Kit Installation Sequence Chapter 2 Before You Begin Before You Begin...
Page 28: Installation Kit
Installation Kit The system management console consists of the SMC PC kit and the terminal server kit. Typically the terminal server kit is installed at the factory. Table 2–1 SMC PC Kit Part Number Description 3X–DS8BA–xx BOM for SMC PC kit; contains these items: See note 3R–A1605–xx...
Page 29 SMC PC kit.) The components of the SMC PC kit are installed at the site. When the SMC is ordered with the GS80/160/320 system, the terminal server and cables are installed in the GS160/320 power cabinet or the GS80 cabinet at the factory.
Page 30: Installation Sequence
Installation Sequence Before installing the terminal server, check that the keyswitch and all AC input box breakers on the GS80/160/320 system are turned to Off. The following is the recommended sequence of installation for the GS80/160/320 system and the system management console: 1.
Page 31: Chapter 3 Connecting The Smc In A System With Multiple Serial Console Lines
Sections in this chapter are: Set Up the SMC Cable the Terminal Server to the SMC Cable the Terminal Server to the GS80/160/320 Make the Cable Connection Record the Connections...
Page 32: Gs80/160/320 Keyswitch
Set Up the SMC Follow the instructions enclosed with the SMC system and monitor to set them up, then start the system. With the GS80/160/320 keyswitch turned off, turn on the AC input box breakers. Make cable connections. Log on to the SMC system. Figure 3–1 GS80/160/320 Keyswitch PK-2737-00 Figure 3–2 Windows NT Security Window...
Page 33: Connecting The Smc In A System With Multiple Serial Console Lines
1. Set up the Compaq Deskpro computer and monitor according to the accompanying instructions. 2. Start the SMC system. As the system software loads, enter information when requested: user name, company name, product ID, and system name. See the AlphaServer GS80/160/320 System Management Console Installation and Release Notes for instructions.
Page 34: Cable The Terminal Server To The Smc
Cable the Terminal Server to the SMC Connect the management channel connector on the terminal server to network adapter 2 on the SMC system. Figure 3–3 Terminal Server Management Channel Connector 1. Connect one end of the BN24Q–07 cable (17–04308–05) to the management channel connector on the terminal server ( 2.
Page 35: Network Adapter 2
Figure 3–4 Network Adapter 2 Minitower Model DPENCM Minitower Model DPENM NOTE: The model type is on a label on the top or side of the SMC box. Connecting the SMC in a System with Multiple Serial Console Lines Desktop Box Model DPENL Desktop Box Model DPEND...
Page 36: Cable The Terminal Server To The Gs80/160/320
Cable the Terminal Server to the GS80/160/320 For PCI boxes in an expander cabinet, make the cable connection to the terminal server. Then record the connections in the table provided and dress the cables. 3.3.1 Make the Cable Connection Cable the local port of the PCI box to the appropriate port on the terminal server with a BN25G cable.
Page 37: Terminal Server Ports
Table 3–1 Terminal Server Cabling Terminal Server Port Figure 3–6 Terminal Server Ports Connecting the SMC in a System with Multiple Serial Console Lines QBB Number GS80 GS160 — — — — — — — — — — GS320 PK-1770-00...
Page 38: Record The Connections
3.3.2 Record the Connections Record the connections made for this installation in Table 3–2. Table 3–2 Terminal Server Cabling at This Installation Terminal Server Port SMC Installation and User’s Guide PCI Box Number QBB Number...
Page 39: Dress The Cables
Dress the Cables Form a service loop and tie wrap the BN25G cable to the rail. Figure 3–7 Terminal Server Cable 1. At the PCI box end, tie wrap the BN25G cable (17–03212–05) to the CSB junction cable (17–04936–xx) to form a service loop ( 2.
Page 40: Cable The Smc To The Corporate Network
Cable the SMC to the Corporate Network Connect to the corporate network from network adapter 1 on the SMC system. Figure 3–8 Network Adapter 1 Minitower Model DPENCM Minitower Model DPENM NOTE: The model type is on a label on the top or side of the SMC box. 3-10 SMC Installation and User’s Guide Desktop Box...
Page 41 Connect a network cable to network adapter 1 on the SMC system, as shown in Figure 3–8. (This cable is not included in the SMC installation kit.) The network adapters are numbered from left to right on the minitower and from bottom to top on the desktop.
Page 43 Connecting the SMC in a System with A system with a single console line is a GS80/160/320 system that has only one standard I/O (SIO) module. The SIO module is in a PCI box connected to a quad building block, and on it is the SRM console firmware, which provides a command-line interface for operator control of the system.
Page 44: Windows Nt Security Window
Set Up the SMC Follow the instructions enclosed with the SMC system and monitor to set them up, then start the system. With the GS80/160/320 keyswitch turned off, turn on the AC input box breakers. Make cable connections. Log on to the SMC system. Figure 4–1 GS80/160/320 Keyswitch PK-2737-00 Figure 4–2 Windows NT Security Window...
Page 45: Connecting The Smc In A System With One Serial Console Line
1. Set up the Compaq Deskpro computer and monitor according to the accompanying instructions. 2. Start the SMC system. As the system software loads, enter information when requested: user name, company name, product ID, and system name. See the AlphaServer GS80/160/320 System Management Console Installation and Release Notes for instructions.
Page 46: Cable The Smc To The Gs80/160/320
Cable the SMC to the GS80/160/320 Connect the COM1 port of the SMC system to the local port of the GS80/160/320. Figure 4–3 COM1 Port Minitower Model DPENCM COM1 (A) Minitower Model DPENM COM1 (A) NOTE: The model type is on a label on the top or side of the SMC box. SMC Installation and User's Guide Desktop Box Model DPENL...
Page 47: Local Port Connection
Install H8585–AA connectors (12–36054–01) on the COM1 (or A) port of the SMC system (Figure 4–3) and the local port of the standard I/O module in the GS80/160/320 system primary PCI box ( in Figure 4–4). Connect these ports with a BN24Q cable (17–04308–05). Figure 4–4 Local Port Connection PK-1724-00 Connecting the SMC in a System with One Serial Console Line...
Page 48: Cable The Smc To The Corporate Network
Cable the SMC to the Corporate Network Connect to the corporate network from the network adapter on the SMC system. Figure 4–5 Network Adapter 1 Minitower Model DPENCM Minitower Model DPENM NOTE: The model type is on a label on the top or side of the SMC box. SMC Installation and User's Guide Desktop Box Model DPENL...
Page 49 Connect a network cable to network adapter 1 on the SMC system, as shown in Figure 4–5. (This cable is not included in the SMC installation kit.) The network adapters are numbered from left to right on the minitower and from bottom to top on the desktop.
Page 50: Check The Com1 Settings
Check the COM1 Settings Check that the baud rate for the COM1 port is 9600. Change it if it is set to any other speed. Check the other COM1 settings. Figure 4–6 Ports Dialog Box SMC Installation and User's Guide...
Page 51: Settings For Com1 Dialog Box
1. From the Start button select Settings|Control Panel. 2. In the control panel, double-click the Ports icon. The Ports dialog box displays (Figure 4–6). 3. Select COM1 and click the Settings… button. The Settings for COM1 dialog box displays (Figure 4–7). 4.
Page 53: Chapter 5 Configuring The Smc Software
These sections apply to all systems: Set the SMC System Time, Date, and Time Zone Configure the Network Connections Enter the Mail Server Name in the ConsoleWorks Script Configure Outlook Express Delete Unused Consoles in ConsoleWorks These sections apply only to systems that have multiple consoles:...
Page 54: Set The Smc System Time, Date, And Time Zone
Set the SMC System Time, Date, and Time Zone Use the Date/Time icon in the Control Panel to set the time, date, and time zone. Figure 5–1 Date & Time Tab SMC Installation and User’s Guide...
Page 55: Time Zone Tab
1. From the Start button select Settings|Control Panel. The Control Panel window displays. 2. In the Control Panel double-click the Date/Time icon. The Date/Time Properties dialog box displays. 3. In the Date & Time tab, set the date and time (Figure 5–1). 4.
Page 56: Configure The Network Connections
Configure the Network Connections Verify the computer name and the protocol for the private LAN. Specify the IP address. Finally, set up the adapter for the corporate network. 5.2.1 Verify the Computer Name Figure 5–3 Identification Changes Dialog Box SMC Installation and User’s Guide...
Page 57 Select the appropriate option button and enter the workgroup or domain name. NOTE: The computer name entered in step 3 cannot be GSSMC1. This name is reserved for the terminal server. Configuring the SMC Software...
Page 58: Verify The Network Protocol
5.2.2 Verify the Network Protocol Figure 5–4 Network Dialog Box SMC Installation and User’s Guide...
Page 59: Select Network Protocol Dialog Box
3. In the Network dialog box, click the Add… button. The Select Network Protocol dialog box displays (Figure 5–5). Highlight TCP/IP Protocol. Click OK. A box displays with a message that begins “If there is a DHCP server on your network….” Click No.
Page 60: Configure Network Adapter 1
5.2.3 Configure Network Adapter 1 Figure 5–6 Microsoft TCP/IP Properties NOTE: The IP address values in the illustration are an example only. Obtain the correct values for this installation from the network administrator. SMC Installation and User’s Guide...
Page 61 The SMC requires a static IP address; it cannot have a dynamic address (that is, an address assigned by a DHCP server). 1. In the Adapter box of the Microsoft TCP/IP Properties dialog box (Figure 5–...
Page 62: Configure Network Adapter 2
5.2.4 Configure Network Adapter 2 Figure 5–7 Microsoft TCP/IP Properties Dialog Box 5-10 SMC Installation and User’s Guide...
Page 63 1. In the Network dialog box, select the Protocols tab. Click the Properties button. 2. The Microsoft TCP/IP Properties dialog box displays (Figure 5–7). Select adapter 2. 3. Select the option button labeled Specify an IP address. Enter the following information: IP address: Subnet mask:...
Page 64: Bind The Protocol
5.2.5 Bind the Protocol Figure 5–8 Bindings Tab in the Network Dialog Box 1. In the Network dialog box, select the Bindings tab. A box with a progress bar displays. 2. When the progress bar indicates that the operation is finished, click Close. 3.
Page 65: Verify The Network Setup
5.2.6 Verify the Network Setup Figure 5–9 Verifying the Network Setup 1. Open a Command window: From the Start menu select Programs| Command Prompt. 2. At the prompt type ping 90.0.0.100. The response should look similar to the first command in Figure 5–9. 3.
Page 66: Enter The Mail Server Name In The Consoleworks Script
Enter the Mail Server Name in the ConsoleWorks Script Modify the file MAIL.PL to include the name of the mail server. This file is in the folder C:\Cwks\Actions\Event. Example 5–1 Modifying the ConsoleWorks Script (MAIL.PL) #!/usr/local/bin/perl # Note: This is written in a very simple version of Perl for # non-experts) # In perl, a single character match is the period ".",...
Page 67 Modify the file MAIL.PL to include the name of the mail server. This file is in the folder C:\Cwks\Actions\Event. 1. Open MAIL.PL in Notepad or another text editor. 2. Find the line ‘$remote = “my.email.server.name.net”;’ ( The example shows an excerpt from the file; for a full listing of MAIL.PL, see Appendix D.)
Page 68: Configure Outlook Express
Configure Outlook Express Obtain mail server information from the network administrator before configuring. Figure 5–10 Internet Accounts Dialog Box 1. Double-click the Outlook Express icon on the desktop. If this is the first time Outlook Express is opened, a box displays asking where messages should be stored.
Page 69: Account_Name Properties Dialog Box
The names of the incoming and outgoing mail servers. 5. When Outlook Express sends or receives mail, by default it removes the messages from the server. To leave a copy of messages on the server, do the following: a. From the Tools menu select Accounts. In the Internet Accounts window right-click on the account name and select Properties from the pop-up menu.
Page 70: Delete Unused Consoles In Consoleworks
Delete Unused Consoles in ConsoleWorks Start and log on to ConsoleWorks. Select Consoles and Delete Console. Figure 5–12 ConsoleWorks Delete Console Screen 5-18 SMC Installation and User’s Guide...
Page 71: Delete Console Verification Message
The default configuration for ConsoleWorks is eight consoles. If the GS80/160/320 system has fewer than eight consoles (that is, fewer than eight PCI boxes with standard I/O modules that are connected to the terminal server), delete the extras in ConsoleWorks.
Page 72: Configure The Terminal Server: Access Server Loader
Configure the Terminal Server: Access Server Loader Access Server Loader configures the IP address and subnet mask of the terminal server. 5.6.1 Open Access Server Loader Figure 5–14 Access Server Loader Window 5-20 SMC Installation and User’s Guide...
Page 73: Access Server Loader Confirm Dialog Box
1. Start Access Server Loader: From the Start menu select Programs|Access Server Loader|Access Server Loader. The Access Server Loader window displays (Figure 5–14). 2. Click Setup. The Confirm dialog box displays (Figure 5–15). Click Yes. Figure 5–15 Access Server Loader Confirm Dialog Box...
Page 74: Create The Database
5.6.2 Create the Database Figure 5–16 Access Server Loader Configuration Dialog Box 5-22 SMC Installation and User’s Guide...
Page 75: Location Of Hardware Address Label
Subnet Mask: 255.255.255.0 NOTE: The IP address you enter in the Access Server Loader Configuration dialog box is the IP address for the terminal server, not for the host. 2. Click OK. The Access Server Loader window displays. Figure 5–17 Location of Hardware Address Label Configuring the SMC Software in Figure 5–17)
Page 76: Verify The Connection
5.6.3 Verify the Connection Figure 5–18 Access Server Loader Window Figure 5–19 Verifying the Connection 5-24 SMC Installation and User’s Guide...
Page 77 1. Check that the terminal server has power (Section B.4 or C.4). 2. Check that the cable from the terminal server to the SMC system is connected correctly (Section 3.4). 3. Check that the position identifier dial on the terminal server is set correctly (Section B.3 or C.3).
Page 78: Configure The Terminal Server: Access Server Manager
Configure the Terminal Server: Access Server Manager Access Server Manager configures the terminal server for access by the SMC system. 5.7.1 Open Access Server Manager Figure 5–20 New Access Server Window 5-26 SMC Installation and User’s Guide...
Page 79: Access Server Dialog Box
Access Server Manager|Access Server Manager. The Access Server Manager window displays. 2. From the File menu select New. The New Access Server dialog box displays (Figure 5–20). The default Login Password is access and the default Privileged Password is system. Click OK.
Page 80: Test The Connection
5.7.2 Test the Connection Figure 5–22 Access Server Dialog Box, Utilities Tab 5-28 SMC Installation and User’s Guide...
Page 81: Telnet Window
1. In the Access Server dialog box, select the Utilities tab (Figure 5–22). Select Test Connection. Click the Do It Now… button. The message “Access Server connection test successful” displays. Click OK. 2. Select Connect to Telnet Console. Click the Do It Now… button. The Telnet window displays (Figure 5–23).
Page 82: Configure Access Server Manager
5.7.3 Configure Access Server Manager Figure 5–24 Select a Command File Dialog Box 5-30 SMC Installation and User’s Guide...
Page 83: Run Command File Dialog Box
1. From the Utilities tab of the Access Server dialog box (Figure 5–22), select Run Command File. 2. Click the Do It Now… button. The Select a Command File dialog box displays (Figure 5–24). 3. Select the file GS_CON.cmds. Click Open. The Run Command File dialog box displays (Figure 5–25).
Page 84: Replace The Consoleworks Configuration File
Replace the ConsoleWorks Configuration File The default configuration file put in place by the SMC installation process is for multiple-console systems. If this system has only one console, replace the configuration file. Figure 5–26 Configuration Files Folder 5-32 SMC Installation and User’s Guide...
Page 85 1. In Windows Explorer go to the folder C:\Cwks\Config (Figure 5–26). 2. Copy the file SERIAL_COM1_DEFAULT.CONFIG: a. Click on the file to highlight it. b. From the Edit menu select Copy. 3. From the Edit menu select Paste. A file named Copy of SERIAL_COM1_DEFAULT.CONFIG is pasted into the folder.
Page 87: Chapter 6 Configuring The Smc For Remote Use
Configuring the SMC for Remote Use Sections in this chapter are: Set Up the Modem Configure the Remote Access Software NOTE: When you have finished setting up the modem and configuring the remote access software, restart the SMC system and set the keyswitch on the GS80/160/320 to On.
Page 88: Set Up The Modem
Set Up the Modem Follow the manufacturer’s instructions for cabling the modem. Figure 6–1 COM2 Port Minitower Model DPENCM COM2 (B) Minitower Model DPENM COM2 (B) NOTE: The model type is on a label on the top or side of the SMC box. 1.
Page 89: Modem Detected
2. Open the Control Panel: From the Start menu select Settings|Control Panel. 3. Double-click the Modems icon. The Install New Modem dialog box displays. Click Next. The operating system detects the modem and tests it. 4. The Install New Modem dialog box displays, with the words Standard Modem in the box.
Page 90: Configure The Remote Access Software
Configure the Remote Access Software Configure both remote access applications, Carbon Copy Access Edition and WinVNC. 6.2.1 Carbon Copy Access Edition Figure 6–3 Communication Properties Dialog Box SMC Installation and User's Guide...
Page 91: Carbon Copy Access Edition Window
1. Start Carbon Copy Access Edition: From the Start menu select Programs|Carbon Copy Access Edition|Carbon Copy. 2. From the Options menu select Communications. The Communication Properties dialog box displays (Figure 6–3). NOTE: Check with the customer before setting up the Wait for Call feature. 3.
Page 92: Winvnc
6.2.2 WinVNC Figure 6–5 Default Local System Properties Dialog Box 1. Display the WinVNC settings: from the Start menu select Programs| VNC|Administrative Tools|Show Default Settings. The Default Local System Properties dialog box displays (Figure 6–5). 2. Enter a password and select the checkboxes shown in Figure 6–5. SMC Installation and User's Guide...
Page 93: Part 3 Using The System Management Console
Part 3 Using the System Management Console...
Page 95: Chapter 7 Getting Started With The System Management Console
Chapter 7 Getting Started with the System Management Console Sections in this chapter are: Logging on to the SMC Using the SMC Locally Using the SMC Remotely Keep in Mind Getting Started with the System Management Console...
Page 96: Logging On To The Smc
Logging on to the SMC Logon is automatic if the administrator account has no password. For manual logon, a different account can be used, or the administrator account can be given a password. Figure 7–1 Windows NT Security Window The SMC system is configured to log on to the administrator account automatically when it powers up.
Page 97: Change Password Dialog Box
If the administrator account is reconfigured to use a password, the Log On dialog box always displays when the PC powers up. You can give that account a password by following these instructions. 1. Press Ctrl+Alt+Del. The Windows NT Security window displays (Figure 7– 2.
Page 98: Using The Smc Locally
Using the SMC Locally Icons on the SMC desktop are used to run applications locally. Figure 7–3 SMC Desktop The SMC desktop has several icons that enable you to run applications and view documentation online. Table 7–1 shows the icons and describes the result of double-clicking each.
Page 99: Smc Desktop Icons
ConsoleWorks Administration/User Guide for more in-depth information. NOTE: Since ConsoleWorks runs in the Internet Explorer Runs Compaq AlphaServer Partition Manager (CAPM), an application that simplifies the creation of partitions on the GS80/160/320 system. Chapter 9 describes this application. Displays a PDF file of the AlphaServer GS80/160/320 System Management Console Installation and User’s Guide (this...
Page 100: Using The Smc Remotely
Using the SMC Remotely The SMC Web page is used to run applications remotely. Figure 7–4 SMC Web Page SMC Installation and User's Guide...
Page 101 CAPM requires that JRE 1.3.0_01 or later be installed on the system from which it is run. Compaq Insight Manager (CIM) – Insight Manager is a system management product that monitors the operations of Compaq servers, workstations, desktops, and portables.
Page 102: Keep In Mind
Keep in Mind Keep these points in mind when you use the system management console. An SMC may be used with only one GS80/160/320 system. Do not attach it to multiple systems or other equipment. The GS80/160/320 SCM and SRM may not have associated passwords. The SCM escape sequence must be the default, <Esc><Esc>scm.
Page 103: Chapter 8 Consoleworks
Managing Consoles Loading Certificate Authority Deleting a Console Adding a Console Renaming a Console Managing Events and Actions Adding an Event Importing and Using Compaq- Supplied Events Enabling an Action Adding a Scan Acknowledging and Purging Events Expunging Events Chapter 8...
Page 104: Starting Consoleworks
Starting ConsoleWorks Start ConsoleWorks from the desktop icon or from the SMC Web page. Figure 8–1 SMC Web Page SMC Installation and User’s Guide...
Page 105 You can run ConsoleWorks from the SMC system or from a workstation networked to the SMC system. To run ConsoleWorks from the SMC system, double-click the ConsoleWorks desktop icon: To run ConsoleWorks from a workstation networked to the SMC system, click the icon on the SMC Web page (Figure 8–1).
Page 106: Overview Of Consoleworks
Overview of ConsoleWorks ConsoleWorks is a Web-based application that monitors console output and provides console management functions. Compaq provides a script that customizes ConsoleWorks for the system management console and GS80/160/320 environment. Figure 8–2 ConsoleWorks Application and Script C:\Cwks\import_pcm SCM.port...
Page 107: Mail Message From Consoleworks
SCM or SRM output. Each event is part of one or more scans, or collection of events. A scan, in turn, is associated with one or more consoles. Compaq has customized the ConsoleWorks application used in the SMC to monitor for particular events and to send mail to user-specified recipients when those events occur.
Page 108: Consoleworks Screen
ConsoleWorks Screen The ConsoleWorks screen is divided into three sections: left navigation panel, main data panel, and lower navigation panel. Figure 8–4 ConsoleWorks Screen SMC Installation and User’s Guide...
Page 109 Figure 8–4 shows the first screen that displays after you log in to ConsoleWorks. The three parts of the screen are described below. Left navigation panel – This panel is divided into three segments (from top to bottom): Function links (Consoles, Groups, Send Message, and Logout). Clicking any of these results in either the display of new information in the main data panel or the display of a new popup window.
Page 110: Managing Consoles
Managing Consoles ConsoleWorks provides access to each console line in a GS80/160/320 system directly from the SMC. Figure 8–5 Show Consoles Screen SMC Installation and User’s Guide...
Page 111 ConsoleWorks is used to manage the console lines in a GS80/160/320 system. To find information about a console line, start by clicking the Consoles link in the left navigation panel of any ConsoleWorks screen to display the Show Consoles screen (Figure 8–5). From there you can view a console line’s activity or its configuration, delete a console (Section 8.4.2) or add one (Section 8.4.3).
Page 112: Loading Certificate Authority
8.4.1 Loading Certificate Authority The Java applet used in ConsoleWorks warns of a potential security violation on the SMC PC. By loading the certificate authority, which is on the C drive with the application, you agree that content from TECSys Development, Inc. can be trusted. Privileges required: Admin –...
Page 113: File Download Dialog Box
When you open a console, a security warning displays (Figure 8–6). To prevent repeated display of this warning, load the TDI security certificate. 1. In the left navigation panel of any ConsoleWorks screen, select Download. 2. From the selection links at the bottom of the left navigation panel, select TDI Certificate.
Page 114: Tdi Certificate
Figure 8–8 TDI Certificate 8-12 SMC Installation and User’s Guide...
Page 115: Root Certificate Store Window
4. The certificate displays (Figure 8–8). Click Install Certificate…. 5. The Certificate Manager Import Wizard displays. Follow the instructions in the wizard and accept the defaults. At the end click Finish. 6. The Root Certificate Store window displays (Figure 8–9). Click Yes. 7.
Page 116: Deleting A Console
8.4.2 Deleting a Console Select Consoles in the left navigation panel, then Delete Console at the top of the screen. Privileges required: Admin – R W C; Console – none Figure 8–10 Delete Console Screen 8-14 SMC Installation and User’s Guide...
Page 117: Delete Console Verification Message
NOTE: Be sure you want to delete the console, since you cannot undo this operation. If you accidentally delete a console, use the Add Console function (Section 8.4.3) to reconfigure it. 1. In the left navigation panel select Consoles. The Show Consoles screen displays.
Page 118: Adding A Console
8.4.3 Adding a Console Select Consoles in the left navigation panel, then Add Console at the top of the screen. The type is Telnet. Do not attempt to add a console if eight consoles already exist. Privileges required: Admin – R W C; Console – none Figure 8–12 Add Telnet Console Screen 8-16 SMC Installation and User’s Guide...
Page 119 In the IP Host block enter 90.0.0.1. d. In the IP Port block enter a number between 2001 and 2008; the last digit is the terminal server port to which the console is attached. This number must be unique for each console.
Page 120: Console_Name Configuration Screen
Figure 8–13 console_name Configuration Screen 8-18 SMC Installation and User’s Guide...
Page 121 5. Click the Add Console button. The console_name Configuration screen displays (Figure 8–13). 6. Enter the profile access information at the bottom of the main data panel. Click the Update button. 7. At the top of the screen select Connect. A window displays showing console line activity.
Page 122: Renaming A Console
8.4.4 Renaming a Console ConsoleWorks does not allow direct renaming of a console. To change a name, delete the console and add a new one with the preferred name. Privileges required: Admin – R W C; Console – none Figure 8–14 console_name Configuration Screen 8-20 SMC Installation and User’s Guide...
Page 123 The SMC is configured with eight default consoles, CONSOLE_1 through CONSOLE_8, which have the attributes needed by this system. Since ConsoleWorks does not allow direct renaming of a console, to change a name, you must delete the console and add a new one with the name you choose. NOTE: If the Show Consoles screen lists eight consoles (not including the ConsoleWorks internal console, CONWRKS), be sure to delete the console before adding a new one.
Page 124: Managing Events And Actions
Managing Events and Actions An event is a text string in the input or output of a console’s SCM, SRM, or operating system instance for which ConsoleWorks monitors. Based on the event, ConsoleWorks can trigger an action. Each event is associated with one or more scans, or collection of events.
Page 125 ConsoleWorks tests. The string can be to or from the SCM, SRM, or operating system. A number of events are supplied by ConsoleWorks and by Compaq; the user can create others (Section 8.5.1). Compaq supplies a number of events that are specific to the GS80/160/320 system (Section 8.5.2).
Page 126: Adding An Event
8.5.1 Adding an Event Select Manage|Events in the left navigation panel, then Add Event at the top of the screen. Privileges required: Admin – R W C; Console – none Figure 8–16 Add Event Screen 8-24 SMC Installation and User’s Guide...
Page 127 1. In the left navigation panel select Manage. From the selection links select Events. The Show Event screen displays. 2. At the top of the Show Event screen select Add Event. The Add Event screen displays (Figure 8–16). 3. Enter the information for the event: a.
Page 128: Importing And Using Compaq-Supplied Events
8.5.2 Importing and Using Compaq-Supplied Events The Compaq-supplied events and script send mail to a designated individual if any of seven conditions occurs in the GS80/160/320 system. Some configuration is required to enable these actions. Table 8–1 Compaq-Supplied Events Event...
Page 129 The Compaq-supplied events warn of a number of AlphaServer conditions that require attention (Table 8–1). These events must be brought into ConsoleWorks before they can be used. Unless ConsoleWorks is re-installed, this procedure is done only once. To import the Compaq-supplied events into ConsoleWorks, do the following: 1.
Page 130: Enabling An Action
8.5.3 Enabling an Action Each event can have a number of associated actions. Privileges required: Admin – R W C; Console – none Figure 8–17 Event event_name Screen 8-28 SMC Installation and User’s Guide...
Page 131: Event Event_Name Actions Screen
1. In the left navigation panel select Manage. From the selection links select Events. The Show Events screen displays. 2. Select the event link from the list. The Event event_name screen displays (Figure 8–17). 3. Select the Automatic Actions link (above the Pattern box). The Event event_name Actions screen displays (Figure 8–18).
Page 132: Mail From Consoleworks
Figure 8–19 Mail from ConsoleWorks 8-30 SMC Installation and User’s Guide...
Page 133 6. Click the checkbox(es) of the action or actions that you want to have triggered by the event. Four items are listed; they represent the four files in the folder C:\Cwks\Actions\Event. Three of them represent valid actions: AUTOCANCEL.BAT – Acknowledge an event immediately after it occurs and, optionally, purge it.
Page 134: Adding A Scan
8.5.4 Adding a Scan Select Manage|Scans in the left navigation panel, then Add Scan at the top of the screen. Privileges required: Admin – R W C; Console – none Figure 8–20 Add Scan Screen 1. In the left navigation panel select Manage. From the selection links select Scans.
Page 135: Scan Scan_Name Screen
3. Enter the information for the scan: a. Scan – Name of the scan, limited to 30 characters. b. Description – Description of the event, maximum 126 characters. 4. Click the Add Scan button. The Scan scan_name screen displays. 5. At the top of the screen select Events. A list of events displays; all are shown as excluded.
Page 136: Acknowledging And Purging Events
8.5.5 Acknowledging and Purging Events Click Events Detail. Select individual events or the Select All link. Click Acknowledge Selected Events, then Purge Acknowledged Events. Privileges required: Acknowledge: Admin – none; Console – R A Delete: Admin – none; Console – R A W C Figure 8–22 ConsoleWorks Events Detail Screen 1.
Page 137: Acknowledged Event
All consoles: From the lower navigation panel select Events Detail. The ConsoleWorks Events Detail screen displays (Figure 8–22). 2. Select the event or events to acknowledge. Individual events: Each occurrence of an event is listed on a line. Click in the checkbox on that line to select the event. All events on the page: Click the link Select All.
Page 138: Expunging Events
8.5.6 Expunging Events Expunging acknowledges and deletes all events of a specified priority and lower from a console. Select Admin|Expunge. Select the console or consoles from which events are to be deleted and click Expunge Events. Privileges required: Admin – R W C; Console – none Figure 8–24 Expunge Events Screen Expunging acknowledges and deletes all events of a specified priority and lower from a console in one operation.
Page 139: Expunge Completed Message
7. Stop the ConsoleWorks services: From the Start menu select Settings| Control Panel. Double-click the Services icon. Highlight the ConsoleWorks LMF Server Service; click the Stop button. Repeat with ConsoleWorks Server Service. Close the Services window. 8. Open a Command window: From the Start menu select Programs| Command Prompt.
Page 140: Managing Users
Managing Users The SMC system administrator determines the consoles to which a user has access and the level of that access. The level of access is controlled by a profile; each user is associated with one or more profiles. Figure 8–26 Show Users Screen 8-38 SMC Installation and User’s Guide...
Page 141 Users gain access to consoles through profiles. A profile specifies the privileges granted to any user who is listed in its Users Granted table. Each user has access to one or more profiles but can use only one profile at a time. Profiles specify two types of privileges: Console and Admin (administrative).
Page 142: Adding A User
8.6.1 Adding a User Select Manage|Users in the left panel, then Add User at the screen top. Privileges required: Admin – R W C; Console – none Figure 8–27 Add User Screen 1. In the left navigation panel select Manage. From the selection links select Users.
Page 143: User_Name Screen
b. Description – For information only; not used elsewhere in ConsoleWorks. Password – Must be at least six characters long. d. Verify – Enter the password again. Verify must match Password. 4. Click the Add User button. The user_name screen displays (Figure 8–28). 5.
Page 144: Communicating With Another User
8.6.2 Communicating with Another User To send a message, select Send Message in the left navigation panel. To read messages, click the mailbox icon in the bottom panel. Privileges required: Admin – none; Console – none Figure 8–29 Send a User Message Screen Sending a Message 1.
Page 145: User User_Name Messages Screen
3. Enter the message in the Message text box. The maximum length is 255 characters. 4. Enter the timeout period in the Expires text box and select the units in the dropdown menu to the right of the text box. The default is 1 hour, the minimum 1 minute, and the maximum 9999 days.
Page 146: Changing A User Password
8.6.3 Changing a User Password Select Change|Password in the left navigation panel. Privileges required: Admin – R W C (none for user’s own) ; Console – none Figure 8–31 Change Password Screen 1. In the left navigation panel select Change. From the selection links select Password.
Page 147: Password Change Screen
3. Enter the information for the password: a. Password – The new password; six characters or longer. b. Verify – Retype the new password. 4. Click the Change Password button. The Password Change screen (Figure 8– 32) displays, confirming the change. NOTE: If the password is changed for an account in use, that user’s session ends, and the user must log in with the new password.
Page 148: Adding A Profile
8.6.4 Adding a Profile Select Manage|Profiles in the left navigation panel, then Add Profile at the top of the screen. Privileges required: Admin – R W C; Console – none Figure 8–33 Add Profile Screen 8-46 SMC Installation and User’s Guide...
Page 149 1. In the left navigation panel select Manage. From the selection links select Profiles. The Show Profiles screen displays. 2. At the top of the Show Profiles screen select Add Profile. The Add Profile screen displays (Figure 8–33). 3. Enter the information for the profile: a.
Page 150: Modifying A Profile
8.6.5 Modifying a Profile Select Manage|Profiles in the left navigation panel. Privileges required: Admin – R W C; Console – none Figure 8–35 Show Profiles Screen 8-48 SMC Installation and User’s Guide...
Page 151 1. In the left navigation panel select Manage. From the selection links select Profiles. The Show Profiles screen displays (Figure 8–35). 2. Select the profile to modify from the list. The profile_name screen displays (Figure 8–36). 3. Make the changes to the profile. Click the Update Profile button. Figure 8–36 profile_name Screen ConsoleWorks...
Page 152: Managing Consoleworks Log Files
Managing ConsoleWorks Log Files ConsoleWorks creates log files for each console (CONSOLE_1 through CONSOLE_8 and CONWRKS). These logs are text files that can be viewed or deleted through ConsoleWorks or by accessing them in the directory. Figure 8–37 console_name Logfiles Screen 8-50 SMC Installation and User’s Guide...
Page 153 ConsoleWorks creates a new log file for each console (CONSOLE_1 through CONSOLE_8 and CONWRKS) every day at midnight. These log files are on the SMC hard drive in the directory D:\CWKS\LOG. The naming convention is console_name.LOG_yyyy_mm_dd. The logs for CONSOLE_1 through CONSOLE_8 show all activity on the console.
Page 154: Viewing A Log File
8.7.1 Viewing a Log File Select Consoles in the left navigation panel. Then select the console from the list. At the top of the screen select the Logs link and the log to view from the list. Privileges required: Admin – none; Console – R Figure 8–38 Log File Screen 8-52 SMC Installation and User’s Guide...
Page 155 1. From the left navigation panel select Consoles. The Show Consoles screen displays. 2. Select the console from the list. The console_name Configuration screen displays. 3. At the top of the screen select Logs. The console_name Logfiles screen displays (Figure 8–37). 4.
Page 156: Deleting Log Files
8.7.2 Deleting Log Files Select Consoles in the left navigation panel. Then select the console from the list. At the top of the screen select the Logs link Privileges required: Admin – ; Console – Figure 8–39 console_name Logfiles Screen 8-54 SMC Installation and User’s Guide...
Page 157 1. From the left navigation panel select Consoles. The Show Consoles screen displays. 2. Select the console from the list. The console_name Configuration screen displays. 3. At the top of the screen select Logs. The console_name Logfiles screen displays (Figure 8–39). 4.
Page 158: Mailing A Log File
8.7.3 Mailing a Log File Start Outlook Express, then include the log file as an attachment. Figure 8–40 Outlook Express Message Window 8-56 SMC Installation and User’s Guide...
Page 159 1. Double-click the Outlook Express icon on the SMC desktop. The Outlook Express Window displays. 2. From the Compose menu select New Message. The New Message window displays (Figure 8–40). 3. Enter recipients' names or addresses and the subject. The title bar text changes to the subject.
Page 160: Saving The Configuration
Saving the Configuration Once you have established the ConsoleWorks configuration, save it to a Zip or floppy disk, D drive, or a network drive so you can easily restore it if ConsoleWorks must be reinstalled. Shut down ConsoleWorks before saving the configuration. Figure 8–41 Windows NT Explorer 8-58 SMC Installation and User’s Guide...
Page 161 You can save the configuration to a Zip disk or floppy disk, or to the D drive on the SMC or a network drive. Saving the Configuration 1. If ConsoleWorks is running, shut it down. 2. From the Start menu select Programs|Windows NT Explorer. 3.
Page 162: Using Kea! With Consoleworks
Using KEA! with ConsoleWorks Select Change|Connect Settings in the left navigation panel. Then select the option button labeled Use Java Telnet Proxy. Select Consoles in the left navigation panel, then select the console from the list. Use the desktop icon to open KEA! and create a new session. Privileges required: Admin –...
Page 163: Telnet Proxy Status Window
1. Select Change in the left navigation panel. From the selection links select Connect Settings. The Console Connection Settings screen displays (Figure 8–42). Select the Use Java Telnet Proxy option button. The change takes effect immediately. 2. In the left navigation panel select Consoles. The Show Consoles screen displays.
Page 164: Kea! Connection Window
Figure 8–44 KEA! Connection Window 8-62 SMC Installation and User’s Guide...
Page 165: Chapter 9 Compaq Alphaserver Partition Manager
Compaq AlphaServer Partition The Compaq AlphaServer Partition Manager (CAPM) simplifies creation of partitions. Sections in this chapter are: Starting CAPM Overview of CAPM Partition Maps Working With Hard Partitions Creating Hard Partitions Adding a Hard Partition Deleting a Hard Partition...
Page 166: Starting Capm
Starting CAPM Start CAPM from the SMC desktop icon or from the SMC Web page. Figure 9–1 SMC Web Page SMC Installation and User's Guide...
Page 167 SMC: ConsoleWorks LMF Server Service, ConsoleWorks Server Service, and Compaq CAPM Server. Additionally, if you run CAPM from the SMC Web page, the Compaq SMC HMMO Server service must be running on the SMC system. All of these services are started automatically when the SMC starts.
Page 168: Overview Of Capm
Overview of CAPM CAPM enables the user to partition a GS80/160/320 system without using console commands. Figure 9–2 Login Box SMC Installation and User's Guide...
Page 169 Compaq AlphaServer Partition Manager (CAPM) is a graphical application that simplifies the creation and management of partitions system. CAPM runs on the SMC and, through a wizard-like series of screens, enables you to work with partitions without having to know anything about the console commands involved.
Page 170: Partition Maps
Partition Maps The partition map provides partitioning information about the GS80/160/320 system. Figure 9–3 Sample Partition Map NOTE: Partition numbering in CAPM differs from partition numbering shown in the output of console commands. SMC Installation and User's Guide...
Page 171 Roll the mouse over a button at the bottom of the screen to see a description of it in the block above the buttons. CAPM uses only hard QBB numbers. See the AlphaServer GS80/160/320 Firmware Reference Manual for a discussion of hard and soft QBB numbers. Compaq AlphaServer Partition Manager...
Page 172: Working With Hard Partitions
Working With Hard Partitions Hard partitions do not share resources. CAPM can create, add, and delete hard partitions and modify, save, validate, and commit partition maps. Figure 9–4 Current Partition Map Screen SMC Installation and User's Guide...
Page 173 Using CAPM, you can perform several operations on hard partitions. These procedures are described in the following sections: Creating Hard Partitions Adding a Hard Partition Deleting a Hard Partition Modifying a Partition Map Saving, Validating, and Committing a Partition Map Loading a Saved Partition Map Compaq AlphaServer Partition Manager...
Page 174: Creating Hard Partitions
9.4.1 Creating Hard Partitions Figure 9–5 Work with Partition Maps Screen 9-10 SMC Installation and User's Guide...
Page 175 3. Enter a number in the box labeled Number of partitions. Click Next. If the GS80/160/320 system does not have sufficient resources to create the number of partitions specified, a message displays indicating that the system has insufficient resources. Compaq AlphaServer Partition Manager Continued on page 9-13 9-11...
Page 176: Create/Modify A Partition Map
Figure 9–6 Create/Modify a Partition Map 9-12 SMC Installation and User's Guide...
Page 177 When this new partition map displays, the operating system (OS Type) is listed as Unknown for each partition. To specify the operating system for a partition, select the partition in the map and click Modify…. (See Section 9.4.3.) Compaq AlphaServer Partition Manager 9-13...
Page 178: Adding A Hard Partition
9.4.2 Adding a Hard Partition Figure 9–7 Add/Modify Hard Partition Screen 1. From the Current Partition Map screen (Figure 9–4) click Next. The Work with Partition Maps screen displays (Figure 9–5). 2. Select the option button labeled Modify the current partition map. The Create/Modify Partition Map screen displays (Figure 9–6).
Page 179: Add/Modify Hard Partition Screen
QBB that is powered and if the hardware requirements for a valid partition have been met. Memory in the unpowered QBB cannot be seen until the QBB is powered on. Figure 9–8 Add/Modify Hard Partition Screen Compaq AlphaServer Partition Manager 9-15...
Page 180: Deleting A Hard Partition
9.4.3 Deleting a Hard Partition Figure 9–9 Create/Modify a Partition Map Screen 1. From the Current Partition Map screen (Figure 9–4) click Next. The Work with Partition Maps screen displays (Figure 9–5). 2. Select the option button labeled Modify the current partition map. The Create/Modify a Partition Map screen displays (Figure 9–9).
Page 181: Delete Confirmation Message
When a hard partition is deleted, all of its resources are returned to Unassigned, indicating that the hardware is not part of any partition, as shown in Figure 9–11. Figure 9–10 Delete Confirmation Message Figure 9–11 Current Partition Map Showing Unassigned Partition Compaq AlphaServer Partition Manager 9-17...
Page 182: Modifying A Partition Map
9.4.4 Modifying a Partition Map Figure 9–12 Work with Partition Maps Screen 1. From the Current Partition Map screen (Figure 9–4) click Next. The Work with Partition Maps screen displays (Figure 9–12). 2. Select the option button labeled Modify the current partition map. Click Next.
Page 183: Add/Modify Hard Partition Screen
OK. The Create/Modify a Partition Map screen returns. 6. Repeat steps 3 through 5 to modify other partitions. NOTE: A QBB can be assigned to only one partition at a time. Figure 9–13 Add/Modify Hard Partition Screen Compaq AlphaServer Partition Manager 9-19...
Page 184: Saving, Validating, And Committing A Partition Map
9.4.5 Saving, Validating, and Committing a Partition Map Figure 9–14 Saving a Partition Map Figure 9–15 Validating a Partition Map Saving a Partition Map 1. In the Create/Modify a Partition Map screen click the Save As… button. An information box displays (Figure 9–14). 2.
Page 185: Committing A Partition Map
GS80/160/320 system and restarts the system. A status box displays (Figure 9–16), showing the progress of the commit, and the commit status is written to the log file. (See Section 9.6.) Figure 9–16 Committing a Partition Map Compaq AlphaServer Partition Manager 9-21...
Page 186: Loading A Saved Partition Map
9.4.6 Loading a Saved Partition Map Figure 9–17 Work with Partition Maps Screen 9-22 SMC Installation and User's Guide...
Page 187 Sections 9.4.2 through 9.4.5. CAPM does not validate the partition map file when it loads. To ensure that the map is valid, click the Validate button in the Create/Modify a Partition Map screen. (See Section 9.4.5.) Compaq AlphaServer Partition Manager 9-23...
Page 188: Working With Soft Partitions
Working With Soft Partitions Soft partitions can share memory, and CPUs can be moved among them. CAPM can create soft partitions by two methods. Figure 9–18 Add/Modify Hard Partition Screen Showing Soft Partitioning Options 9-24 SMC Installation and User's Guide...
Page 189 NOTE: Do not attempt to create soft partitions if the hard partition contains an unpowered QBB. Commit the hard partitions first (see Section 9.4.5), and then create the soft partitions. When the hard partitions are committed, the unpowered QBB is powered on. Compaq AlphaServer Partition Manager 9-25...
Page 190: Basic Soft Partitioning
9.5.1 Basic Soft Partitioning Figure 9–19 Basic Soft Partitioning Message Figure 9–20 Basic Soft Partition Screen 9-26 SMC Installation and User's Guide...
Page 191 Amount of Total Memory allocated to Shared Memory – An amount of memory is allocated to shared memory. The lower limit is 64 MB; the upper limit is the total of memory for all soft partitions within the hard partition less 128 MB. Compaq AlphaServer Partition Manager 9-27...
Page 192: Adding A Soft Partition
9.5.2 Adding a Soft Partition Figure 9–21 Add/Modify Soft Partition Screen 9-28 SMC Installation and User's Guide...
Page 193 64 MB blocks, so the amount shown is a multiple of 64. b. Select the checkbox labeled Allocate shared memory equally among QBBs to take an equal (or nearly equal) amount of memory from each QBB in the hard partition for the shared memory. Compaq AlphaServer Partition Manager 9-29...
Page 194: Modifying A Soft Partition
9.5.3 Modifying a Soft Partition Figure 9–22 Basic Soft Partition Screen; Modifying a Partition 9-30 SMC Installation and User's Guide...
Page 195: Add/Modify Soft Partition Screen
3. The Basic Soft Partition screen returns. Optionally change the amount of shared memory by moving the slider to the preferred amount and change the allocation by clicking the checkbox labeled Allocate shared memory equally among QBBs. Click OK. Figure 9–23 Add/Modify Soft Partition Screen Compaq AlphaServer Partition Manager 9-31...
Page 196: Deleting A Soft Partition
9.5.4 Deleting a Soft Partition Figure 9–24 Basic Soft Partition Screen; Deleting a Partition Figure 9–25 Delete Confirmation 9-32 SMC Installation and User's Guide...
Page 197: Basic Soft Partition Screen; Partition Deleted
2. A message displays, asking for confirmation of the action (Figure 9–25). Click the appropriate button. 3. The Basic Soft Partition screen updates if you chose to delete the partition. (See Figure 9–26.) Click OK. Figure 9–26 Basic Soft Partition Screen; Partition Deleted Compaq AlphaServer Partition Manager 9-33...
Page 198: Advanced Soft Partitioning
9.5.5 Advanced Soft Partitioning Figure 9–27 Advanced Soft Partition Screen 9-34 SMC Installation and User's Guide...
Page 199 Enter values for these environment variables in the column on the right. Click OK. For descriptions of the AlphaServer SRM environment variables used to create soft partitions, and examples of using them, see the AlphaServer GS80/160/320 Getting Started with Paritions manual. Compaq AlphaServer Partition Manager 9-35...
Page 200: Managing Capm Files
Managing CAPM Files CAPM creates log files and partition map files. Example 9–1 Excerpt from a CAPM Log File [Tue Dec 05 12:01:03 EST 2000, pmu.ccm.CwkCCM, 0, Info] Successful login by console_manager [Tue Dec 05 12:01:04 EST 2000, pmu.PMUServerImpl, 3, Trace] Discovery beginning [Tue Dec 05 12:01:04 EST 2000, pmu.PMUServerImpl, 6, Trace] Discovering console WF2...
Page 201 This is for ease of sorting and processing. CAPM partition map files are written to C:\SMC\CAPM\MAPS. This is done only when you select the Save As… button and provide a file name. The default extension is .PMF. Compaq AlphaServer Partition Manager 9-37...
Page 203: Chapter 10 Graphical Configuration Utility
Graphical Configuration Utility The Graphical Configuration Utility (GCU) is an OpenVMS Galaxy utility for creating and maintaining partitions. Sections in this chapter are: Setting Up the GCU Using the GCU Chapter 10 Graphical Configuration Utility 10-1...
Page 204: 10.1 Setting Up The Gcu
10.1 Setting Up the GCU Define information for the Galaxy instances in the eXcursion Control Panel. 10.1.1 Establish Access Control Figure 10–1 eXcursion Control Panel Access Tab 10-2 SMC Installation and User's Guide...
Page 205 1. From the Start menu select Programs|eXcursion V7|eXcursion Control Panel. The eXcursion Control Panel window opens with the Info tab displayed. 2. Select the Access tab (Figure 10–1). 3. In the Access tab select the Enable Access Control checkbox, enter the Node Name, and click the Add button.
Page 206: 10.1.2 Create An Account For Each Galaxy Instance
10.1.2 Create an Account for Each Galaxy Instance Figure 10–2 Accounts Tab 10-4 SMC Installation and User's Guide...
Page 207 1. In the eXcursion Control Panel window select the Accounts tab (Figure 10– 2. Enter the Account Alias, Host name, Username, and Password. Click the Add button. 3. Repeat step 2 for each instance. Graphical Configuration Utility 10-5...
Page 208: 10.1.3 Define The Applications
10.1.3 Define the Applications Figure 10–3 Applications Tab 10-6 SMC Installation and User's Guide...
Page 209 1. In the eXcursion Control Panel window select the Applications tab (Figure 10–3). 2. Enter an alias in the Application Alias box. 3. In the Command box enter $mcr gcu. 4. Select an Account Alias from the drop-down list. 5. Click the Add button. 6.
Page 210: 10.2 Using The Gcu
10.2 Using the GCU From the eXcursion icon select Applications and the Galaxy instance. Figure 10–4 eXcursion Icon 10-8 SMC Installation and User's Guide...
Page 211 Guide for information on managing Galaxy partitions. This manual is available in HTML and PDF formats on the Web. Go to URL http://www.openvms.compaq.com:8000/ and click the link OpenVMS Operating System. Scroll down the list to OpenVMS Alpha Galaxy Guide. Graphical Configuration Utility...
Page 213: Part 4 Troubleshooting
Part 4 Troubleshooting...
Page 215 This chapter contains troubleshooting tips for the system management console hardware and software. Sections in this chapter are: Troubleshooting Chart Changing Baud Rates: System with Multiple Console Lines Changing Baud Rates: System with Single Console Line Changing the Internet Explorer Proxy Setting Starting the ConsoleWorks Services Configuring the SMC System to Restart After a Power Failure Setting the Path Variable...
Page 216: 11.1 Troubleshooting Chart
DEFAULT.CONFIG (one console line) in the same folder. Rename it DEFAULT.CONFIG. Change attributes from read only to read/write. Connect the terminal server to the power source (Section B.4 for GS160/320 or C.4 for GS80 system). Configure the software (Sections 5.6 and 5.7).
Page 217 UNIX; terminal server’s or SMC’s baud rate is not 9600. Suggested Solution Change the cable to a BN24Q. Reload the terminal server using Access Server Manager (Section 5.7). No action required. Change the baud rate (Sections 11.2 and 11.3). Check the console settings in the ConsoleWorks console configura- tion screen (Section 8.4.3).
Page 218 (Section 8.4.2). Acknowledge (Section 8.5.5) or expunge (Section 8.5.6) events. Delete the file and copy 8_CONSOLE_DEFAULT.CONFIG (systems with a terminal server) or SERIAL_COM1_ DEFAULT.CONFIG (no terminal server) to DEFAULT.CONFIG. Expunge events, and export and import the database (Section 8.5.6) Change Internet Explorer settings (Section 11.4).
Page 219 (Section 11.5). Start the CAPM service in the same way as the ConsoleWorks services (Section 11.5). The service name is Compaq CAPM Server. Start the CAPM service in the same way as the ConsoleWorks services (Section 11.5). The service name is Compaq CAPM Server.
Page 220 Exit ConsoleWorks (but leave the ConsoleWorks services running). Start the service in the same way as the ConsoleWorks services (Section 11.5). The service name is Compaq SMC HMMO Server. Install JRE for Windows NT from the SMC software CD (\SMC_V3_1_kit\JRE\j2re- 1_3_0_01-win-i.exe). JRE for other platforms can be found at the site www.javasoft.com.
Page 221 Table 11–1 Troubleshooting (Continued) Symptom Possible Cause SMC Web Page (continued) You are using Netscape V6.0 with Windows 98. Clicking a link to Acrobat Reader is either of the user not the correct guides does not version. display the manual. Restart after Power Fail The SMC system The system has not...
Page 222: Changing Baud Rates: System With Multiple Console Lines
Change the terminal server port’s baud rate to match the GS80/160/320 partition’s rate and establish communication. Then change the partition baud rate to 9600, and finally change the terminal server rate to 9600. 11.2.1 Set the Terminal Server Port Speed to Match the GS80/160/320 Partition Speed Figure 11–1 Browser Window...
Page 223: Ports Configuration Dialog Box
1. Open Access Server Manager (ASM). From the Start menu select Programs|Access Server Manager|Access Server Manager. A Browser window displays (Figure 11–1). 2. In the Browser window select the item with IP address 90.0.0.1. Click Open. The Access Server window displays.
Page 224: Configuration Dialog Box
Figure 11–3 Configuration Dialog Box 11-10 SMC Installation and User’s Guide...
Page 225: Connection Service Configuration Dialog Box
4. Select the port for which you will change the baud rate and click the Configure… button. The Configuration dialog box displays (Figure 11–3). 5. Click the Properties button. The Connection Service Configuration dialog box displays (Figure 11–4). 6. Change the port speed in this box, and check that the other settings are correct for your environment.
Page 226: 11.2.2 Test For A Baud Rate Match And Set Both To 9600
11.2.2 Test for a Baud Rate Match and Set Both to 9600 Figure 11–5 Show Consoles Screen 11-12 SMC Installation and User’s Guide...
Page 227 3. In the terminal emulator window press Enter. If the SCM or SRM console prompt displays, the baud rate of the terminal server port matches that of the GS80/160/320 partition. If no console prompt displays, return to Section 11.2.1 and set the terminal server port to a different speed.
Page 228: Set The Smc System Speed To Match The Gs80/160/320 Speed
11.3 Changing Baud Rates: System with Single Console Line Change the baud rate of the system’s COM1 port to match the GS80/160/320 system and establish communication. Then change the system rate to 9600, and finally change the COM1 rate to 9600. 11.3.1 Set the SMC System Speed to Match the GS80/160/320 Speed Figure 11–6 Ports Dialog Box...
Page 229: Settings For Com1 Dialog Box
1. From the Start button select Settings|Control Panel. 2. In the control panel, double click the Ports icon. The Ports dialog box displays (Figure 11–6). 3. Select COM1 and click the Settings… button. The Settings for COM1 dialog box displays (Figure 11–7). 4.
Page 230: 11.3.2 Test For A Baud Rate Match And Set Both To 9600
11.3.2 Test for a Baud Rate Match and Set Both to 9600 Figure 11–8 Show Consoles Screen 11-16 SMC Installation and User’s Guide...
Page 231 1. In the left navigation panel of a ConsoleWorks window, select Consoles. The Show Consoles screen displays (Figure 11–8). 2. Click the icon to the left of the CONSOLE_1 link. A terminal emulator window for the console displays. 3. In the terminal emulator window press Enter. If an SRM console prompt displays, the baud rates match, and you can set the GS80/160/320 baud rate (step 4).
Page 232: 11.4 Changing The Internet Explorer Proxy Setting
11.4 Changing the Internet Explorer Proxy Setting From the Internet Explorer Tools menu select Internet Options. Select the Connections tab and LAN Settings. Figure 11–9 LAN Settings Dialog Box – Automatic Configuration 11-18 SMC Installation and User’s Guide...
Page 233: Lan Settings Dialog Box - Proxy Server
In the Automatic configuration section click the checkbox labeled Automatically detect settings (Figure 11–9). Click OK. In the Proxy server section click the checkbox labeled Use a proxy server (Figure 11–10). In the Address box enter the proxy server address for your site.
Page 234: 11.5 Starting The Consoleworks Services
11.5 Starting the ConsoleWorks Services Open the Control Panel and double-click the Services icon. Select the ConsoleWorks services and click Start. Figure 11–11 ConsoleWorks Services 11-20 SMC Installation and User’s Guide...
Page 235: Service Dialog Box
1. Open the Control Panel. From the Start button select Settings|Control Panel. 2. In the Control Panel double-click the Services icon. The Services dialog box displays (Figure 11–11). 3. Check the Status and Startup columns for the two ConsoleWorks services. If one or both do not look like the illustration, do the following: a.
Page 236: Configuring The Smc System To Restart After A Power Failure
11.6 Configuring the SMC System to Restart After a Power Failure The SMC system should power up and boot following a power failure. If it does not, corrective action is necessary. The action to take depends on the system model. Figure 11–13 Switch Setting for Models DPENM and DPEND PK-2733-00 11-22...
Page 237 Models ENCM and ENL 1. Start or restart the SMC system. 2. During power up, at the initial screen with the large Compaq logo, press the F10 key for setup. A list of languages, with English selected, displays. Press Enter 3.
Page 238: 11.7 Setting The Path Variable
11.7 Setting the Path Variable Open the Control Panel and double-click the System icon. In the Environment tab select Path and add the path to the Java Runtime Environment in the Value box. Figure 11–14 System Properties Dialog Box 11-24 SMC Installation and User’s Guide...
Page 239 1. From the Start menu, select Settings | Control Panel. Double-click the System icon. The System Properties dialog box displays. 2. Select the Environment tab (Figure 11–14). 3. In the System Variables block, highlight the Path variable. The name and value of the variable display near the bottom of the dialog box, in the Name and Value boxes, respectively.
Page 241: Appendix A Using The Smc Software Cd
The AlphaServer Console Management Software CD installs the following applications on the SMC hard disk: ConsoleWorks for AlphaServer Perl and scripts to customize ConsoleWorks Compaq AlphaServer Partition Manager Service Pack 5 for Microsoft Windows NT Internet Explorer KEA! Acrobat Reader...
Page 242 In addition, shortcuts are placed on the desktop for the following: ConsoleWorks for AlphaServer Compaq AlphaServer Partition Manager KEA! ConsoleWorks Administration/User Guide (PDF format) AlphaServer GS80/160/320 System Management Console Installation and User’s Guide (a PDF version of this manual) SMC Installation and User’s Guide...
Page 243: Appendix B Installing A Terminal Server In A Gs160/320 System
Remove the Existing Connection from the SMC System to the GS160/320 Attach the Mounting Brackets Install the Terminal Server in the GS160/320 Power Cabinet Connect the Terminal Server to the Power Source Cable the Terminal Server to the SMC System...
Page 244: B–1 Com1 Port
Remove the Existing Connection from the SMC System to the GS160/320 Remove the cable between the SMC system and the GS160/320. Figure B–1 COM1 Port Minitower Model DPENCM COM1 (A) Minitower Model DPENM COM1 (A) NOTE: The model type is on a label on the top or side of the SMC box. SMC Installation and User’s Guide Desktop Box Model DPENL...
Page 245: Pci Box Rear - Local Port Connection
GS160/320 ( NOTE: The COM1 port might be labeled A. 2. Remove the H8585–AA connector from the COM1 port. Figure B–2 PCI Box Rear – Local Port Connection Installing a Terminal Server in a GS160/320 System in Figure B–2). PK-1724-00...
Page 246: B–3 Mounting Brackets
Attach the Mounting Brackets Position the top rear holes over the alignment pins. Fasten the brackets with the M5 screws. Figure B–3 Mounting Brackets PK-1767-00 SMC Installation and User’s Guide...
Page 247 ( ) on the terminal server tray. The front end of the bracket should be 2 inches (5 cm) from the front of the terminal server. (The front is the face that has the port connectors.) 2. Fasten the bracket to the terminal server with the M5 screws ( 3.
Page 248: B–4 Position Identifier Dial
Install the Terminal Server in the GS160/320 Power Cabinet Set the position identifier dial to management agent and install the terminal server in the power cabinet. Figure B–4 Position Identifier Dial SMC Installation and User’s Guide PK-1768-00...
Page 249: Terminal Server Placement In The Gs160/320 System
1. Set the position identifier dial at the rear of the terminal server to management agent (the position after 14; Figure B–4). 2. Attach the power cord to the rear of the terminal server power supply. Do not plug the other end into the power source yet.
Page 250: Connect The Terminal Server To The Power Source
Connect the Terminal Server to the Power Source Connect the power cord to J19 of the bottom AC input box. Figure B–6 GS160/320 AC Input Box PK-1726-00 SMC Installation and User’s Guide...
Page 251 Plug the power cord of the terminal server into J19 of AC input box 1 (the bottom AC input box) in the GS160/320 power cabinet. If the GS160/320 system is powered up, the terminal server powers up when it is plugged in.
Page 252: Cable The Terminal Server To The Smc System
Cable the Terminal Server to the SMC System Connect the management channel connector on the terminal server to network adapter 2 on the SMC system. Figure B–7 Terminal Server Management Channel Connector 1. Connect one end of the BN24Q–07 cable (17–04308–05) to the management channel connector on the terminal server ( 2.
Page 253: B–8 Network Adapter 2
Minitower Model DPENCM Minitower Model DPENM NOTE: The model type is on a label on the top or side of the SMC box. Installing a Terminal Server in a GS160/320 System Desktop Box Model DPENL Desktop Box Model DPEND PK-1723-00...
Page 254: Cable The Terminal Server To The Gs160/320
Cable the Terminal Server to the GS160/320 For each console, connect a terminal server port to the local port of the PCI box. B.6.1 Make the Cable Connection Figure B–9 PCI Box Rear — Local Port Location Make the connection for each console: 1.
Page 255: Terminal Server Ports
Table B–1 Terminal Server Cabling Terminal Server Port Figure B–10 Terminal Server Ports Installing a Terminal Server in a GS160/320 System QBB Number GS160 — — — — GS320 PK-1770A-00 B-13...
Page 256: Record The Connections
B.6.2 Record the Connections Record the connections made for this installation in Table B–2. Table B–2 Terminal Server Cabling at This Installation Terminal Server Port B-14 SMC Installation and User’s Guide PCI Box Number QBB Number...
Page 257: Dress The Cable
2. Tie wrap the 17–03212–05 cable down the rail of the cabinet ( 3. At the bottom of the rail, coil the cable and place the extra length in the rail Installing a Terminal Server in a GS160/320 System PK-1753-00 in Figure B–11).
Page 259: Appendix C Installing A Terminal Server In A Gs80 System
Sections in this chapter include: Remove the Existing Connection from the SMC System to the GS80 Attach the Mounting Brackets Install the Terminal Server in the GS80 Rack Connect the Terminal Server to the Power Source Cable the Terminal Server to the SMC System...
Page 260: C.1 Remove The Existing Connection From The Smc System To The Gs80
C.1 Remove the Existing Connection from the SMC System to the GS80 Remove the cable between the SMC system and the GS80. Figure C–1 COM1 Port Minitower Model DPENCM COM1 (A) Minitower Model DPENM COM1 (A) NOTE: The model type is on a label on the top or side of the SMC box. SMC Installation and User's Guide Desktop Box Model DPENL...
Page 261: Pci Box Rear - Local Port Connection
NOTE: The COM1 port might be labeled A. 2. Remove the H8585–AA connector from the COM1 port of the SMC. Figure C–2 PCI Box Rear – Local Port Connection in Figure C–2). Installing a Terminal Server in a GS80 System PK-1724-00...
Page 262: C.2 Attach The Mounting Brackets
C.2 Attach the Mounting Brackets Position the top rear holes over the alignment pins. Fasten the brackets with the M5 screws. Figure C–3 Mounting Brackets PK-1767-00 SMC Installation and User's Guide...
Page 263 ( ) on the terminal server tray. The front end of the bracket should be 2 inches (5 cm) from the front of the terminal server. (The front is the face that has the port connectors.) 2. Fasten the bracket to the terminal server with the M5 screws ( 3.
Page 264: C.3 Install The Terminal Server In The Gs80 Rack
C.3 Install the Terminal Server in the GS80 Rack Set the position identifier dial to management agent and install the terminal server in the power cabinet. Figure C–4 Position Identifier Dial PK-1768-00 SMC Installation and User's Guide...
Page 265: Terminal Server Placement In The Gs80 System
1. Set the position identifier dial at the rear of the terminal server to management agent (the position after 14; Figure C–4). 2. Attach the power cord to the rear of the terminal server power supply. Do not plug the other end into the power source yet.
Page 266: C.4 Connect The Terminal Server To The Power Source
C.4 Connect the Terminal Server to the Power Source Connect the power cord to J5A or J1 of the bottom AC input box. Figure C–6 GS80 AC Input Box North America Europe and Japan PK-1784-00 SMC Installation and User's Guide...
Page 267 Plug the power cord of the terminal server into AC input box 1 (the bottom AC input box) in the GS80 rack: North America systems (–CA variant), use outlet J4A. Europe and Japan systems (–CB and –CC variants), use outlet J1.
Page 268: C.5 Cable The Terminal Server To The Smc System
C.5 Cable the Terminal Server to the SMC System Connect the management channel connector on the terminal server to network adapter 2 on the SMC system. Figure C–7 Terminal Server Management Channel Connector 1. Connect one end of the BN24Q–07 cable (17–04308–05) to the management channel connector on the terminal server ( 2.
Page 269: C–8 Network Adapter 2
Model DPENCM Minitower Model DPENM NOTE: The model type is on a label on the top or side of the SMC box. Desktop Box Model DPENL Desktop Box Model DPEND Installing a Terminal Server in a GS80 System PK-1723-00 C-11...
Page 270: C–9 Pci Box Rear — Local Port Location
C.6 Cable the Terminal Server to the GS80 For each console, connect a terminal server port to the local port of the PCI box. C.6.1 Make the Cable Connection Figure C–9 PCI Box Rear — Local Port Location Make the connection for each console: 1.
Page 271: C–10 Terminal Server Ports
Table C–1 Terminal Server Cabling Terminal Server Port Figure C–10 Terminal Server Ports Installing a Terminal Server in a GS80 System QBB Number — — — — — — PK-1770-00 C-13...
Page 272: Record The Connections
C.6.2 Record the Connections Record the connections made for this installation in Table C–2. Table C–2 Terminal Server Cabling at This Installation Terminal Server Port C-14 SMC Installation and User's Guide PCI Box Number QBB Number...
Page 273: D.1 Scm.port
Polycenter Console Manager (PCM.). This file is imported to ConsoleWorks to supply definitions of scans and events. The name of the scan is GS_SCM_SCAN. All Compaq-supplied events, which are described in Table D–1, are part of this scan. The event pattern triggers are automatically defined during the import.
Page 274: D.1.2 Contents
All events listed in Table D–1 have a priority of 50 and a severity of critical. Note that event GS_PCI_PBM_SYSEVENT can be triggered by any of three subevents. These are defined and recognized in the Perl script, as described in Section D.2.
Page 275: D.2.2 Contents
MAIL.BAT and MAIL.PL are copied to the event directory, C:\Cwks\Actions\Event. Edit MAIL.PL to change the value of the variable $remote to point to the site’s SMTP mail server. Reference the following comment and modify the next line: # This is site specific $remote = "post-office.domain.com";...
Page 276 Verify that you can connect to the console and receive a prompt. The prompt can be from the SCM, SRM, or operating system. If you do not see a prompt, configure the console as appropriate. Refer to Section D.4 for the contents of the SCM.PORT file. For any event, look for the string located at the TEXT: label.
Page 277: D.4 Contents Of The Scm.port File
REGULAR_EXPRESSION: Y START: 0 COUNT: 1 PRIORITY: CRITICAL END: DELETE_EVENT: NAME: GS_QBB_OVERTEMP_FAILURE END: ADD_EVENT: NAME: GS_QBB_OVERTEMP_FAILURE INFO: Overtemp failure from a PSM TEXT: ~E~ QBB%/PSM%% SysEvent: QBB_OVERTEMP_FAILURE*Reg0:*Reg1:* CLASS: SCM SUB_SYSTEM: CSB REGULAR_EXPRESSION: Y START: 0 Compaq-Supplied Configuration Files for ConsoleWorks...
Page 278 COUNT: 1 PRIORITY: CRITICAL END: DELETE_EVENT: NAME: GS_HS_OVERTEMP END: ADD_EVENT: NAME: GS_HS_OVERTEMP INFO: Overtemp failure from an HPM TEXT: ~E~ HSW%/HPM%% SysEvent: HS_OVERTEMP*Reg0:*Reg1:* CLASS: SCM SUB_SYSTEM: CSB REGULAR_EXPRESSION: Y START: 0 COUNT: 3 PRIORITY: CRITICAL END: DELETE_EVENT: NAME: GS_PWR_FAIL END: ADD_EVENT: NAME: GS_PWR_FAIL INFO: Vital power failure from an HPM...
Page 279 REGULAR_EXPRESSION: Y START: 0 COUNT: 3 PRIORITY: CRITICAL END: DELTE SCAN: NAME: GS_SCM_SCAN END: ADD_SCAN: NAME: GS_SCM_SCAN INFO: SCM ASCII messages EVENT: GS_AIR_MOVER_FAILURE EVENT: GS_VITAL_POWER_FAILURE EVENT: GS_QBB_OVERTEMP_FAILURE EVENT: GS_HS_OVERTEMP EVENT: GS_PWR_FAIL EVENT: GS_SYSCLK_FAIL EVENT: GS_PCI_PBM_SYSEVENT END: Compaq-Supplied Configuration Files for ConsoleWorks...
Page 280: D.5 Contents Of The Mail.pl File
# $ARGV[5] User Supplied Paramter use Socket; sub smtpmail { my ($to, $subj, $whoami, $mf, @msg) = @_; my ($port, $iaddr, $paddr, $proto, $line); # This is site specific $remote = "my.email.server.name.net"; $port = 25; $iaddr = inet_aton($remote) || die "no host: \"$remote\"\n"; $paddr = sockaddr_in($port, $iaddr);...
Page 281 ($_ =~ /^~E~ FAN. FAIL - POWEROFF IN 30 SECONDS/) {next;} if ($_ =~ /^~E~ LM80 . TEMP FAIL/) {next;} if ($_ =~ /^~E~ PS. POK DEASSERTED/) {next;} Other events are just ignored... $domail = 0; Compaq-Supplied Configuration Files for ConsoleWorks #Note the error...
Page 282 close(SC); # The other events are just mail... $subj = "Console $ARGV[0] has Encountered Event $ARGV[1] (Sequence $ARGV[2])"; open (SC, $ARGV[3]) || die "Can not open event context file - $ARGV[3] $!"; while ($l=<SC>) { push @msg, $l; close(SC); if ($domail) { foreach $to (@tolist) { smtpmail($to, $subj, $whoami, $mf, @msg);...
Page 283: Use Of Disk Partitions
The hard disk in the SMC is partitioned at the factory. It is recommended that the partitions be used as shown in Table E–1. Table E–1 Use of Disk Partitions Partition Recommended Use Operating system and applications User setups (unique scripts, other inputs) and log files The directory structure of the C partition is shown in Figure E–1.
Page 284: E–1 C Partition
Figure E–1 C Partition SMC Installation and User's Guide...
Page 285 6-4 Changing computer name, 5-4 Circuit breakers, location, 3-3, 4-3 COM1 port, SMC system, 4-4, 11-14, B- 2, C-2 COM2 port, SMC system, 6-2 Compaq AlphaServer Partition Manager. See CAPM Computer name, changing, 5-4 Configuration ConsoleWorks restoring, 8-59 saving, 8-59 SMC software for multiple consoles, 5-1–5-33...
Page 286 8-9 displaying terminal emulator window, 11-13 does not start, 11-4 events, D-1 acknowledging, 8-34 adding, 8-24 AlphaServer specific, 8-26 Compaq-supplied, 8-26 defined, 8-24 deleting, 8-34 expunging, 8-36 managing, 8-22–8-37 modifying, 8-24 files, managing, 8-50–8-57 left navigation panel, 8-6...
Page 287 C-12 Log file (ConsoleWorks) deleting, 8-54 mailing, 5-16, 8-56 viewing, 8-52 Logging on to ConsoleWorks, 8-3 Mail server, defining in ConsoleWorks, 5-14 MAIL.BAT file, D-2 MAIL.PL file, D-2, D-8 Mailing log files, 5-16 Management channel connector, 3-4 Managing consoles, 8-8–8-21...
Page 288 Ports COM1, 4-4, 4-8, 11-14, B-2, C-2 COM2, 6-2 local (GS80/160/320), 3-6, 4-5, B-12, C-3, C-12 terminal server, 3-7, 11-9, B-13, C-13 Index-4 Position identifier dial, terminal server, 11-2 Powering up the system, 2-4, 3-3, 4-3 Private LAN, configuring, 5-4...
Page 289 11-2 restart after power fail, 11-7 restart after power failure, 11-22 restoring disk, A-1 restrictions, 7-8 running applications remotely, 7-6 setting up the box and monitor, 3-2, setting up the modem, 6-2 software, 3-3, 4-3...
