3-22 DS20E Reference Guide
Part Number: FR-K8F6W-UA .A01 File Name: d-ch3 Installing a Rack System.doc Last Saved On: 10/4/99 1:25 PM
WARNING: Make sure that all other hardware in the rack is pushed in and
attached.
The system is very heavy. Do not attempt to lift it manually. Use a material lift
or other mechanical device.
1
Figure 3-15. Attaching the System to the Rack
3. Install U-nuts at marked locations for two shipping screws.
4. Install 6-32 hex head shipping screws
Compaq Confidential – Need to Know Required
Writer: Robert Young Project: Compaq AlphaServer DS20E System Comments:
1
CAT0157A
and tighten.
